DETAILED COOLING CAPACITIES*
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX024-B Outdoor Section With FV4BNF002 Indoor Section - High Speed
600
72 30.11 15.15 1.94 28.05 14.32 2.08 26.05 13.53 2.21 24.12 12.78 2.32 22.30 12.09 2.42 20.59 11.45 2.51
67 26.85 18.05 1.89 24.92 17.19 2.02 23.03 16.37 2.14 21.22 15.60 2.24 19.50 14.88 2.33 17.96 14.25 2.41
63†† 24.49 17.28 1.85 22.64 16.40 1.98 20.86 15.58 2.08 19.10 14.78 2.18 17.56 14.09 2.27 16.07 13.43 2.33
62 23.89 20.94 1.84 22.10 20.06 1.96 20.32 19.19 2.07 18.68 18.36 2.17 17.39 17.30 2.26 16.24 16.24 2.34
57 22.50 22.50 1.82 21.12 21.12 1.94 19.80 19.80 2.06 18.52 18.52 2.16 17.33 17.33 2.26 16.25 16.25 2.34
700
72 31.18 16.07 1.97 29.07 15.24 2.12 26.93 14.42 2.24 24.88 13.65 2.36 22.96 12.94 2.46 21.18 12.29 2.55
67 27.85 19.47 1.93 25.79 18.58 2.06 23.78 17.74 2.17 21.88 16.94 2.28 20.10 16.21 2.37 18.48 15.55 2.45
63†† 25.41 18.61 1.89 23.44 17.71 2.01 21.52 16.84 2.12 19.74 16.06 2.22 18.17 15.37 2.31 16.51 14.65 2.37
62 24.85 22.84 1.88 22.91 21.89 2.00 21.12 20.93 2.11 19.70 19.70 2.22 18.38 18.38 2.31 17.21 17.21 2.40
57 23.93 23.93 1.86 22.46 22.46 1.99 21.03 21.03 2.10 19.68 19.68 2.22 18.40 18.40 2.32 17.20 17.20 2.40
800
72 32.06 16.93 2.00 29.74 16.05 2.14 27.54 15.22 2.27 25.43 14.45 2.39 23.47 13.73 2.49 21.58 13.06 2.58
67 28.62 20.80 1.95 26.45 19.89 2.08 24.40 19.04 2.20 22.40 18.22 2.31 20.57 17.48 2.40 18.86 16.76 2.48
63†† 26.10 19.86 1.91 24.03 18.92 2.04 22.08 18.06 2.15 20.25 17.26 2.25 18.46 16.48 2.33 16.88 15.78 2.40
62 25.59 24.57 1.90 23.65 23.50 2.03 22.13 22.12 2.15 20.63 20.63 2.26 19.27 19.27 2.36 18.04 18.04 2.45
57 25.16 25.16 1.90 23.58 23.58 2.03 22.09 22.09 2.15 20.64 20.64 2.26 19.29 19.29 2.36 18.04 18.04 2.45
900
72 32.71 17.72 2.03 30.31 16.82 2.17 28.04 15.99 2.29 25.89 15.21 2.41 23.86 14.49 2.52 21.88 13.80 2.61
67 29.22 22.03 1.98 27.01 21.12 2.11 24.84 20.23 2.23 22.85 19.42 2.34 20.94 18.64 2.43 19.19 17.79 2.51
63†† 26.65 21.04 1.94 24.54 20.10 2.06 22.53 19.22 2.18 20.61 18.35 2.28 18.81 17.55 2.36 17.22 16.80 2.43
62 26.28 26.10 1.93 24.58 24.57 2.07 23.00 22.99 2.19 21.45 21.45 2.30 20.05 20.05 2.41 18.71 18.71 2.49
57 26.19 26.19 1.93 24.56 24.56 2.06 22.97 22.97 2.19 21.46 21.46 2.30 20.05 20.05 2.41 18.71 18.71 2.49
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 024 0.92 1.07 CE3AA 024 0.95 0.98
030 0.95 1.01 030 0.97 0.98
036 0.98 1.06 036 0.98 0.98
CC5A/CD5AW 024 0.92 1.07 CK3BA 024 0.96 0.97
030 0.93 1.06 030 0.97 0.98
036 0.98 1.06 036 0.99 0.99
CE3AA 024 0.93 1.08 CK5A/CK5BA 024 0.99 1.00
030 0.94 1.07 030 0.99 0.99
036 0.96 1.07 036 0.99 0.99
CF5AA 024 0.93 1.07 CK5A/CK5BT 036 0.99 0.99
036 0.95 1.04 CK5A/CK5BW 024 0.99 0.99
CK3BA 024 0.93 1.08 030 0.99 0.99
030 0.94 1.07 CK5PA 024 0.99 1.00
036 0.98 1.08 030 0.99 0.99
CK5A/CK5BA 024 0.93 1.08 036 0.99 0.99
030 0.94 1.07 CK5PT 036 0.99 0.99
036 0.98 1.08 CK5PW 024 0.99 1.00
CK5A/CK5BT 036 0.98 1.08 030 0.99 0.99
CK5A/CK5BW 024 0.93 1.08
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE
030 0.94 1.07 CC5A/CD5AA 024 0.94 0.97
036 0.98 1.08 030 0.96 0.97
CK5PA 024 0.93 1.08 036 0.99 0.98
030 0.94 1.07 CC5A/CD5AW 024 0.94 0.97
036 0.98 1.08 030 0.96 0.97
CK5PT 036 0.98 1.08 036 0.99 0.98
CK5PW 024 0.93 1.08 CE3AA 024 0.96 0.99
030 0.94 1.07 030 0.97 0.98
036 0.98 1.08 036 0.98 0.98
FE4ANF 002 1.00 1.00 CK3BA 024 0.97 0.97
003 1.00 0.99 030 0.98 0.98
FK4DNF 001 0.99 1.00 036 1.00 0.99
FV4BNF 002 1.00 1.00 CK5A/CK5BA 024 0.99 0.99
003 1.00 0.99 030 0.99 0.98
40FKB/FK4DNF 002 1.00 1.00 036 1.00 0.99
003 1.00 0.99 CK5A/CK5BT 036 1.00 0.99
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE CK5A/CK5BW 024 0.99 0.99
CC5A/CD5AA 024 0.94 0.98 030 1.00 0.99
030 0.96 0.98 036 1.00 0.98
036 0.99 0.99 CK5PA 024 0.99 0.99
CC5A/CD5AW 024 0.94 0.98 030 0.99 0.99
030 0.96 0.98 036 0.99 0.98
