—29—
DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX036-B Outdoor Section With FV4BNF006 Indoor Section - Low Speed continued
650
72 22.82 12.62 1.11 21.27 12.05 1.20 19.71 11.40 1.28 18.02 10.82 1.36 16.27 10.26 1.44 14.46 9.63 1.52
67 20.58 15.87 1.11 19.10 15.25 1.19 17.57 14.62 1.26 15.98 14.00 1.34 14.35 13.36 1.42 12.65 12.65 1.48
63†† 18.89 15.19 1.10 17.46 14.56 1.18 16.01 13.93 1.25 14.53 13.30 1.32 13.01 12.65 1.39 11.62 11.58 1.46
62 18.68 18.65 1.09 17.58 17.58 1.18 16.44 16.44 1.25 15.24 15.24 1.33 13.99 13.99 1.41 12.70 12.70 1.49
57 18.70 18.70 1.10 17.58 17.58 1.18 16.44 16.44 1.26 15.24 15.24 1.33 13.99 13.99 1.41 12.70 12.70 1.49
825
72 22.96 13.52 1.13 21.47 13.04 1.21 19.93 12.60 1.29 18.36 12.14 1.37 16.67 11.60 1.46 14.85 10.88 1.54
67 21.34 18.15 1.12 19.78 17.52 1.20 18.17 16.89 1.28 16.52 16.22 1.36 15.08 14.99 1.44 13.63 13.55 1.52
63†† 19.61 17.33 1.11 18.12 16.69 1.19 16.61 16.05 1.27 15.16 15.09 1.34 13.80 13.80 1.42 12.42 12.42 1.49
62 20.33 20.13 1.12 19.01 19.01 1.20 17.74 17.74 1.28 16.42 16.42 1.36 15.05 15.05 1.44 13.60 13.60 1.52
57 20.23 20.23 1.11 19.01 19.01 1.20 17.74 17.74 1.28 16.42 16.42 1.36 15.05 15.05 1.44 13.61 13.61 1.52
1000
72 22.92 14.03 1.14 21.39 13.65 1.22 19.87 13.24 1.31 18.30 12.88 1.39 16.70 12.56 1.47 14.96 12.21 1.55
67 21.85 20.28 1.13 20.25 19.64 1.21 18.71 18.71 1.30 17.29 17.29 1.38 15.81 15.78 1.46 14.28 14.28 1.54
63†† 20.13 19.22 1.13 18.61 18.61 1.21 17.27 17.27 1.28 15.90 15.90 1.36 14.48 14.48 1.44 13.01 12.97 1.52
62 21.38 21.38 1.13 20.07 20.07 1.22 18.71 18.71 1.30 17.29 17.29 1.38 15.80 15.80 1.46 14.28 14.28 1.54
57 21.36 21.36 1.13 20.06 20.06 1.21 18.71 18.71 1.30 17.28 17.28 1.38 15.81 15.81 1.46 14.28 14.28 1.54
1175
72 22.89 14.21 1.15 21.37 13.83 1.23 19.83 13.52 1.32 18.25 13.38 1.40 16.63 13.26 1.49 14.94 13.03 1.56
67 22.25 22.13 1.14 20.83 20.83 1.23 19.39 19.39 1.31 17.89 17.89 1.39 16.35 16.35 1.48 14.73 14.73 1.56
63†† 20.57 20.57 1.14 19.22 19.22 1.22 17.89 17.56 1.30 16.43 16.42 1.38 14.94 14.94 1.46 13.40 13.40 1.54
62 22.22 22.22 1.14 20.83 20.83 1.23 19.39 19.39 1.31 17.89 17.89 1.39 16.35 16.35 1.48 14.73 14.73 1.56
57 22.21 22.21 1.14 20.84 20.84 1.23 19.42 19.42 1.32 17.91 17.91 1.39 16.35 16.35 1.48 14.73 14.73 1.56
1350
72 22.85 14.38 1.16 21.33 14.01 1.24 19.79 13.74 1.33 18.20 13.60 1.41 16.58 13.67 1.50 14.88 13.67 1.58
67 22.60 22.60 1.16 21.13 21.13 1.24 19.62 19.62 1.32 18.05 18.05 1.41 16.45 16.45 1.49 14.84 14.84 1.58
63†† 20.62 20.62 1.15 19.26 19.26 1.23 17.90 17.90 1.31 16.49 16.49 1.39 15.02 15.02 1.47 13.52 13.52 1.55
62 22.60 22.60 1.16 21.12 21.12 1.24 19.62 19.62 1.33 18.08 18.08 1.41 16.50 16.50 1.49 14.84 14.84 1.58
57 22.60 22.60 1.16 21.14 21.14 1.25 19.62 19.62 1.33 18.07 18.07 1.41 16.40 16.40 1.48 14.88 14.88 1.58
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CC5A/CD5AC 048 0.97 1.03 CK5PW 036 0.98 1.04
CC5A/CD5AW 036 0.98 1.04 048 0.99 1.04
042 0.97 1.03
COILS + 355MAV060120 VARIABLE SPEED FURNACE
048 0.98 1.04 CC5A/CD5AA 042 0.97 1.03
CD5AA 048 0.98 1.03 CC5A/CD5AC 048 0.97 1.04
CE3AA 036 0.97 1.04 CC5A/CD5AW 036 0.97 1.03
042 0.98 1.04 042 0.97 1.04
048 0.98 1.03 048 0.97 1.02
CK3BA 036 0.98 1.04 CD5AA 048 0.98 1.04
042 0.98 1.04 CE3AA 036 0.95 1.04
048 0.99 1.04 042 0.98 1.04
CK5A/CK5BA 036 0.98 1.04 048 0.98 1.04
042 0.98 1.04 CK3BA 042 0.98 1.04
048 0.99 1.04 048 0.98 1.03
CK5A/CK5BE 042 0.99 1.04 CK5A/CK5BA 042 0.98 1.04
CK5A/CK5BT 036 0.98 1.04 048 0.98 1.03
042 0.98 1.04 CK5A/CK5BT 042 0.98 1.04
048 0.99 1.04 048 0.98 1.03
CK5A/CK5BW 036 0.98 1.04 CK5A/CK5BW 036 0.98 1.04
048 0.99 1.03 048 0.98 1.03
CK5PA 036 0.98 1.04 CK5PA 042 0.98 1.04
042 0.98 1.04 048 0.98 1.03
048 0.99 1.04 CK5PT 042 0.98 1.04
CK5PE 042 0.99 1.04 048 0.98 1.03
CK5PT 036 0.98 1.04 CK5PW 036 0.98 1.04
042 0.98 1.04 048 0.98 1.03
048 0.99 1.04 — — —
