Bryant 698B - Page 30

—30—
DETAILED COOLING CAPACITIES* continued
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX048-B Outdoor Section With FV4BNF005 Indoor Section - High Speed
1200
72 55.43 27.69 3.74 52.25 26.41 4.00 49.03 25.13 4.25 45.75 23.85 4.52 42.34 22.55 4.78 38.86 21.25 5.04
67 49.95 33.35 3.65 46.98 32.03 3.89 44.00 30.73 4.13 40.89 29.38 4.38 37.71 28.04 4.63 34.46 26.69 4.89
63†† 46.00 32.13 3.57 43.24 30.82 3.81 40.35 29.46 4.03 37.41 28.11 4.28 34.42 26.77 4.51 31.41 25.42 4.76
62 44.99 39.02 3.55 42.24 37.66 3.78 39.48 36.29 4.01 36.62 34.87 4.26 33.78 33.37 4.49 31.28 31.28 4.76
57 42.41 42.41 3.50 40.26 40.26 3.74 38.10 38.10 3.98 35.90 35.90 4.23 33.60 33.60 4.49 31.28 31.28 4.76
1400
72 57.10 29.22 3.83 53.80 27.92 4.09 50.39 26.62 4.34 46.90 25.29 4.61 43.34 23.97 4.87 39.74 22.65 5.14
67 51.50 35.78 3.73 48.42 34.45 3.98 45.19 33.07 4.22 41.91 31.70 4.47 38.60 30.33 4.72 35.25 28.96 4.98
63†† 47.48 34.44 3.66 44.48 33.05 3.89 41.44 31.67 4.12 38.37 30.30 4.37 35.28 28.93 4.61 32.08 27.52 4.85
62 46.47 42.33 3.64 43.60 40.86 3.88 40.68 39.37 4.11 37.78 37.78 4.35 35.36 35.36 4.62 32.81 32.81 4.89
57 44.73 44.73 3.61 42.49 42.49 3.85 40.16 40.16 4.09 37.76 37.76 4.35 35.36 35.36 4.62 32.81 32.81 4.89
1600
72 58.44 30.65 3.91 54.94 29.32 4.17 51.36 27.98 4.42 47.75 26.64 4.69 44.09 25.31 4.95 40.41 23.98 5.23
67 52.73 38.05 3.81 49.42 36.66 4.06 46.08 35.25 4.30 42.70 33.87 4.56 39.30 32.47 4.81 35.84 31.06 5.07
63†† 48.53 36.58 3.73 45.42 35.17 3.97 42.26 33.77 4.20 39.11 32.37 4.45 35.90 30.91 4.69 32.60 29.45 4.94
62 47.66 45.32 3.72 44.69 43.74 3.96 41.84 41.84 4.20 39.36 39.36 4.46 36.74 36.74 4.72 34.07 34.07 5.00
57 46.76 46.76 3.71 44.31 44.31 3.95 41.84 41.84 4.20 39.37 39.37 4.46 36.75 36.75 4.72 34.08 34.08 5.00
1800
72 59.43 31.97 3.98 55.79 30.62 4.24 52.12 29.24 4.50 48.40 27.88 4.77 44.68 26.54 5.03 40.86 25.19 5.30
67 53.60 40.18 3.89 50.19 38.78 4.13 46.75 37.35 4.38 43.30 35.94 4.64 39.84 34.52 4.89 36.27 33.03 5.14
63†† 49.34 38.50 3.81 46.15 37.11 4.05 42.94 35.69 4.28 39.69 34.26 4.53 36.36 32.78 4.77 33.02 31.24 5.01
62 48.67 47.98 3.80 45.85 45.85 4.04 43.31 43.31 4.30 40.64 40.64 4.56 37.92 37.92 4.83 35.18 35.18 5.11
57 48.39 48.39 3.79 45.85 45.85 4.04 43.31 43.31 4.30 40.64 40.64 4.56 37.92 37.92 4.83 35.18 35.18 5.11
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.95 1.02 CE3AA 048 0.96 0.98
CC5A/CD5AC 048 0.92 1.02 060 0.98 0.96
CC5A/CD5AW 048 0.95 1.02 CK3BA 048 0.96 0.97
060 0.93 1.01 060 0.99 0.97
CD5AA 048 0.95 1.02 CK5A/CK5BA 048 0.96 0.97
CE3AA 048 0.93 1.01 060 0.99 0.97
060 0.96 1.02 CK5A/CK5BT 048 0.96 0.97
CK3BA 048 0.93 1.01 060 0.99 0.97
060 0.96 1.02 CK5A/CK5BW 048 0.96 0.96
CK5A/CK5BA 048 0.93 1.01 CK5A/CK5BX 060 1.00 0.97
060 0.96 1.02 CK5PA 048 0.96 0.97
CK5A/CK5BT 048 0.93 1.01 060 0.99 0.97
060 0.96 1.02 CK5PT 048 0.96 0.97
CK5A/CK5BW 048 0.93 1.01 060 0.99 0.97
CK5A/CK5BX 060 0.97 1.02 CK5PW 048 0.96 0.96
CK5PA 048 0.93 1.01 CK5PX 060 1.00 0.97
060 0.96 1.02
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE
CK5PT 048 0.93 1.01 CC5A/CD5AA 060 0.96 0.97
060 0.96 1.02 CC5A/CD5AC 048 0.93 0.97
CK5PW 048 0.93 1.01 CC5A/CD5AW 048 0.95 0.96
CK5PX 060 0.97 1.02 060 0.98 0.97
FE4ANB 006 1.02 0.98 CD5AA 048 0.95 0.96
FE4ANF 005 1.00 1.00 CE3AA 048 0.96 0.98
FV4BNB 006 1.02 0.98 060 0.98 0.97
FV4BNF 005 1.00 1.00 CK3BA 048 0.96 0.97
40FKB/FK4DNB 006 1.02 0.98 060 0.98 0.97
40FKB/FK4DNF 005 1.00 1.00 CK5A/CK5BA 048 0.96 0.98
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE 060 0.98 0.96
CC5A/CD5AC 048 0.93 0.98 CK5A/CK5BT 048 0.96 0.97
CD5AA 048 0.95 0.98 060 0.99 0.98
CE3AA 048 0.95 0.98 CK5A/CK5BW 048 0.96 0.96
CK3BA 048 0.96 0.99 CK5A/CK5BX 060 1.00 0.98
CK5A/CK5BA 048 0.96 0.99 CK5PA 048 0.96 0.98
CK5A/CK5BT 048 0.96 0.99 060 0.98 0.96
CK5PA 048 0.96 0.99 CK5PT 048 0.96 0.97
CK5PT 048 0.96 0.99 060 0.99 0.98
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CK5PW 048 0.96 0.96
CC5A/CD5AA 060 0.96 0.97 CK5PX 060 1.00 0.98
CC5A/CD5AC 048 0.93 0.97
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
CC5A/CD5AW 048 0.95 0.96 CC5A/CD5AA 060 0.96 0.96
CD5AA 048 0.96 0.97 CC5A/CD5AC 048 0.93 0.96
See notes on page 37.
