Bryant 698B - Page 31

—31—
DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX048-B Outdoor Section With FV4BNF005 Indoor Section - High Speed continued
1200
72 55.43 27.69 3.74 52.25 26.41 4.00 49.03 25.13 4.25 45.75 23.85 4.52 42.34 22.55 4.78 38.86 21.25 5.04
67 49.95 33.35 3.65 46.98 32.03 3.89 44.00 30.73 4.13 40.89 29.38 4.38 37.71 28.04 4.63 34.46 26.69 4.89
63†† 46.00 32.13 3.57 43.24 30.82 3.81 40.35 29.46 4.03 37.41 28.11 4.28 34.42 26.77 4.51 31.41 25.42 4.76
62 44.99 39.02 3.55 42.24 37.66 3.78 39.48 36.29 4.01 36.62 34.87 4.26 33.78 33.37 4.49 31.28 31.28 4.76
57 42.41 42.41 3.50 40.26 40.26 3.74 38.10 38.10 3.98 35.90 35.90 4.23 33.60 33.60 4.49 31.28 31.28 4.76
1400
72 57.10 29.22 3.83 53.80 27.92 4.09 50.39 26.62 4.34 46.90 25.29 4.61 43.34 23.97 4.87 39.74 22.65 5.14
67 51.50 35.78 3.73 48.42 34.45 3.98 45.19 33.07 4.22 41.91 31.70 4.47 38.60 30.33 4.72 35.25 28.96 4.98
63†† 47.48 34.44 3.66 44.48 33.05 3.89 41.44 31.67 4.12 38.37 30.30 4.37 35.28 28.93 4.61 32.08 27.52 4.85
62 46.47 42.33 3.64 43.60 40.86 3.88 40.68 39.37 4.11 37.78 37.78 4.35 35.36 35.36 4.62 32.81 32.81 4.89
57 44.73 44.73 3.61 42.49 42.49 3.85 40.16 40.16 4.09 37.76 37.76 4.35 35.36 35.36 4.62 32.81 32.81 4.89
1600
72 58.44 30.65 3.91 54.94 29.32 4.17 51.36 27.98 4.42 47.75 26.64 4.69 44.09 25.31 4.95 40.41 23.98 5.23
67 52.73 38.05 3.81 49.42 36.66 4.06 46.08 35.25 4.30 42.70 33.87 4.56 39.30 32.47 4.81 35.84 31.06 5.07
63†† 48.53 36.58 3.73 45.42 35.17 3.97 42.26 33.77 4.20 39.11 32.37 4.45 35.90 30.91 4.69 32.60 29.45 4.94
62 47.66 45.32 3.72 44.69 43.74 3.96 41.84 41.84 4.20 39.36 39.36 4.46 36.74 36.74 4.72 34.07 34.07 5.00
57 46.76 46.76 3.71 44.31 44.31 3.95 41.84 41.84 4.20 39.37 39.37 4.46 36.75 36.75 4.72 34.08 34.08 5.00
1800
72 59.43 31.97 3.98 55.79 30.62 4.24 52.12 29.24 4.50 48.40 27.88 4.77 44.68 26.54 5.03 40.86 25.19 5.30
67 53.60 40.18 3.89 50.19 38.78 4.13 46.75 37.35 4.38 43.30 35.94 4.64 39.84 34.52 4.89 36.27 33.03 5.14
63†† 49.34 38.50 3.81 46.15 37.11 4.05 42.94 35.69 4.28 39.69 34.26 4.53 36.36 32.78 4.77 33.02 31.24 5.01
62 48.67 47.98 3.80 45.85 45.85 4.04 43.31 43.31 4.30 40.64 40.64 4.56 37.92 37.92 4.83 35.18 35.18 5.11
57 48.39 48.39 3.79 45.85 45.85 4.04 43.31 43.31 4.30 40.64 40.64 4.56 37.92 37.92 4.83 35.18 35.18 5.11
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
High Speed
Indoor
Section Size
High Speed
Capacity Power Capacity Power
CC5A/CD5AW 048 0.96 0.96
COILS + 355MAV060100 VARIABLE SPEED FURNACE
060 0.98 0.96 CC5A/CD5AA 060 0.93 0.99
CD5AA 048 0.96 0.97 CC5A/CD5AC 048 0.92 1.00
CE3AA 048 0.96 0.97 CC5A/CD5AW 048 0.93 0.99
060 0.98 0.96 CD5AA 048 0.93 0.99
CK3BA 048 0.96 0.96 CE3AA 048 0.95 1.01
060 0.98 0.96 060 0.97 1.00
CK5A/CK5BA 048 0.99 1.01 CK3BA 048 0.95 1.00
060 0.98 0.96 060 0.97 1.00
CK5A/CK5BT 048 0.96 0.97 CK5A/CK5BA 048 0.95 1.01
060 0.99 0.97 060 0.97 1.00
CK5A/CK5BW 048 0.96 0.96 CK5A/CK5BT 048 0.95 1.01
CK5A/CK5BX 060 1.00 0.97 060 0.97 1.00
CK5PA 048 0.99 1.01 CK5A/CK5BW 048 0.95 1.00
060 0.98 0.96 CK5PA 048 0.95 1.01
CK5PT 048 0.96 0.97 060 0.97 1.00
060 0.99 0.97 CK5PT 048 0.95 1.01
CK5PW 048 0.96 0.96 060 0.97 1.00
CK5PX 060 1.00 0.97 CK5PW 048 0.95 1.00
COILS + 355MAV060080 VARIABLE SPEED FURNACE COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA 060 0.93 1.00 CC5A/CD5AA 060 0.93 0.99
CC5A/CD5AC 048 0.92 1.00 CC5A/CD5AC 048 0.92 0.99
CC5A/CD5AW 048 0.93 1.00 CC5A/CD5AW 048 0.93 0.99
CD5AA 048 0.93 1.00 CD5AA 048 0.93 0.99
CE3AA 048 0.95 1.01 CE3AA 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK3BA 048 0.93 1.00 CK3BA 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK5A/CK5BA 048 0.93 1.00 CK5A/CK5BA 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK5A/CK5BT 048 0.93 1.00 CK5A/CK5BT 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK5A/CK5BW 048 0.95 1.00 CK5A/CK5BW 048 0.95 0.99
CK5PA 048 0.93 1.00 CK5PA 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK5PT 048 0.93 1.00 CK5PT 048 0.95 1.00
060 0.97 1.01 060 0.97 1.00
CK5PW 048 0.95 1.00 CK5PW 048 0.95 0.99
