—32—
DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX048-B Outdoor Section With FV4BNF005 Indoor Section - Low Speed
850
72 30.89 16.37 1.67 28.81 15.57 1.85 26.68 14.78 2.02 24.53 13.98 2.20 22.34 13.15 2.38 19.94 12.35 2.55
67 27.77 20.19 1.67 25.83 19.37 1.84 23.89 18.56 2.00 21.90 17.75 2.16 19.86 16.93 2.33 17.77 16.06 2.50
63†† 25.54 19.38 1.66 23.78 18.50 1.83 21.88 17.74 1.98 20.03 16.93 2.13 18.16 16.10 2.29 16.22 15.28 2.45
62 24.98 24.02 1.66 23.24 23.11 1.82 22.26 20.89 1.99 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
57 24.58 24.58 1.66 23.24 23.24 1.83 21.77 21.76 1.98 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
1075
72 32.10 18.03 1.69 29.87 17.21 1.88 27.59 16.38 2.06 25.26 15.55 2.23 22.87 14.73 2.41 20.40 13.87 2.59
67 28.89 22.83 1.69 26.76 21.88 1.87 24.70 21.13 2.04 22.59 20.28 2.20 20.45 19.41 2.37 18.38 18.25 2.54
63†† 26.58 21.86 1.69 24.61 21.00 1.85 22.66 20.15 2.02 20.69 19.30 2.17 18.74 18.41 2.34 16.93 16.93 2.50
62 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.12 20.12 2.36 18.34 18.34 2.54
57 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.11 20.11 2.36 18.33 18.33 2.54
1300
72 32.88 19.56 1.72 30.51 18.72 1.90 28.14 17.88 2.09 25.71 17.04 2.26 23.23 16.19 2.44 20.68 15.33 2.62
67 29.60 25.29 1.72 27.44 24.39 1.90 25.26 23.48 2.07 23.10 22.54 2.24 21.11 21.11 2.41 19.21 18.99 2.59
63†† 27.26 24.15 1.72 25.22 23.26 1.89 23.20 22.35 2.05 21.26 21.26 2.21 19.50 19.50 2.38 17.66 17.66 2.55
62 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 22.93 22.93 2.23 21.11 21.11 2.41 19.19 19.19 2.59
57 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 23.04 23.04 2.25 21.11 21.11 2.41 19.14 19.14 2.59
1525
72 33.39 21.00 1.75 30.96 20.12 1.93 28.50 19.28 2.11 26.03 18.42 2.29 23.47 17.57 2.47 20.83 16.68 2.65
67 30.13 27.53 1.75 27.91 26.59 1.92 25.74 25.53 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.85 19.48 2.64
63†† 27.78 26.23 1.75 25.72 25.23 1.92 23.82 23.82 2.08 22.01 22.01 2.25 20.15 20.15 2.42 18.23 18.22 2.60
62 29.33 29.33 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.75 19.75 2.63
57 29.34 29.34 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.83 21.83 2.45 19.76 19.76 2.63
1750
72 33.75 22.32 1.77 31.26 21.46 1.96 28.76 20.59 2.14 26.21 19.77 2.32 23.62 18.89 2.50 20.93 17.97 2.69
67 30.57 29.57 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
63†† 28.24 28.00 1.77 26.35 26.35 1.95 24.49 24.49 2.12 22.60 22.60 2.28 20.66 20.66 2.46 18.62 18.62 2.63
62 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.45 24.45 2.31 22.40 22.40 2.49 20.23 20.23 2.67
57 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.99 1.11
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE
CC5A/CD5AC 048 0.98 1.11 CC5A/CD5AA 060 1.00 1.03
CC5A/CD5AW 048 0.99 1.11 CC5A/CD5AC 048 1.00 1.04
060 1.00 1.11 CC5A/CD5AW 048 1.00 1.02
CD5AA 048 0.99 1.11 CD5AA 048 1.00 1.03
CE3AA 048 0.94 1.25 CE3AA 048 1.00 1.03
060 1.00 1.11 060 1.00 1.01
CK3BA 048 1.00 1.11 CK3BA 048 1.00 1.02
060 1.00 1.11 060 1.00 1.00
CK5A/CK5BA 048 1.00 1.11 CK5A/CK5BA 048 1.00 1.02
060 1.00 1.11 060 1.00 1.00
CK5A/CK5BT 048 1.00 1.11 CK5A/CK5BT 048 1.00 1.02
060 1.00 1.11 060 1.00 1.00
CK5A/CK5BW 048 1.00 1.11 CK5A/CK5BW 048 1.00 1.01
CK5A/CK5BX 060 1.00 1.11 CK5A/CK5BX 060 1.06 1.05
CK5PA 048 1.00 1.11 CK5PA 048 1.00 1.02
060 1.00 1.11 060 1.00 1.00
CK5PT 048 1.00 1.11 CK5PT 048 1.00 1.02
060 1.00 1.11 060 1.00 1.00
CK5PW 048 1.00 1.11 CK5PW 048 1.00 1.01
CK5PX 060 1.00 1.11 CK5PX 060 1.00 0.99
FE4ANB 006 1.02 0.98
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE
FE4ANF 005 1.00 1.00 CC5A/CD5AA 060 1.00 1.02
FV4BNB 006 1.02 0.98 CC5A/CD5AC 048 1.00 1.04
FV4BNF 005 1.00 1.00 CC5A/CD5AW 048 1.00 1.02
40FKB/FK4DNB 006 1.02 0.98 060 1.00 1.00
40FKB/FK4DNF 005 1.00 1.00 CD5AA 048 1.00 1.02
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE CE3AA 048 1.00 1.03
CC5A/CD5AC 048 1.00 1.04 060 1.00 1.00
CD5AA 048 1.00 1.03 CK3BA 048 1.00 1.02
CE3AA 048 1.00 1.03 060 1.00 1.00
CK3BA 048 1.00 1.02 CK5A/CK5BA 048 1.00 1.01
CK5A/CK5BA 048 1.00 1.02 060 1.00 1.00
CK5A/CK5BT 048 1.00 1.02 CK5A/CK5BT 048 1.00 1.02
CK5PA 048 1.00 1.02 060 1.00 1.00
CK5PT 048 1.00 1.02 — — —
