DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX048-B Outdoor Section With FV4BNF005 Indoor Section - Low Speed continued
850
72 30.89 16.37 1.67 28.81 15.57 1.85 26.68 14.78 2.02 24.53 13.98 2.20 22.34 13.15 2.38 19.94 12.35 2.55
67 27.77 20.19 1.67 25.83 19.37 1.84 23.89 18.56 2.00 21.90 17.75 2.16 19.86 16.93 2.33 17.77 16.06 2.50
63†† 25.54 19.38 1.66 23.78 18.50 1.83 21.88 17.74 1.98 20.03 16.93 2.13 18.16 16.10 2.29 16.22 15.28 2.45
62 24.98 24.02 1.66 23.24 23.11 1.82 22.26 20.89 1.99 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
57 24.58 24.58 1.66 23.24 23.24 1.83 21.77 21.76 1.98 20.30 20.30 2.14 18.80 18.80 2.31 17.19 17.19 2.48
1075
72 32.10 18.03 1.69 29.87 17.21 1.88 27.59 16.38 2.06 25.26 15.55 2.23 22.87 14.73 2.41 20.40 13.87 2.59
67 28.89 22.83 1.69 26.76 21.88 1.87 24.70 21.13 2.04 22.59 20.28 2.20 20.45 19.41 2.37 18.38 18.25 2.54
63†† 26.58 21.86 1.69 24.61 21.00 1.85 22.66 20.15 2.02 20.69 19.30 2.17 18.74 18.41 2.34 16.93 16.93 2.50
62 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.12 20.12 2.36 18.34 18.34 2.54
57 26.61 26.61 1.69 25.04 25.04 1.86 23.45 23.45 2.03 21.82 21.82 2.19 20.11 20.11 2.36 18.33 18.33 2.54
1300
72 32.88 19.56 1.72 30.51 18.72 1.90 28.14 17.88 2.09 25.71 17.04 2.26 23.23 16.19 2.44 20.68 15.33 2.62
67 29.60 25.29 1.72 27.44 24.39 1.90 25.26 23.48 2.07 23.10 22.54 2.24 21.11 21.11 2.41 19.21 18.99 2.59
63†† 27.26 24.15 1.72 25.22 23.26 1.89 23.20 22.35 2.05 21.26 21.26 2.21 19.50 19.50 2.38 17.66 17.66 2.55
62 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 22.93 22.93 2.23 21.11 21.11 2.41 19.19 19.19 2.59
57 28.13 28.13 1.72 26.45 26.45 1.89 24.70 24.70 2.06 23.04 23.04 2.25 21.11 21.11 2.41 19.14 19.14 2.59
1525
72 33.39 21.00 1.75 30.96 20.12 1.93 28.50 19.28 2.11 26.03 18.42 2.29 23.47 17.57 2.47 20.83 16.68 2.65
67 30.13 27.53 1.75 27.91 26.59 1.92 25.74 25.53 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.85 19.48 2.64
63†† 27.78 26.23 1.75 25.72 25.23 1.92 23.82 23.82 2.08 22.01 22.01 2.25 20.15 20.15 2.42 18.23 18.22 2.60
62 29.33 29.33 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.82 21.82 2.45 19.75 19.75 2.63
57 29.34 29.34 1.75 27.52 27.52 1.92 25.68 25.68 2.10 23.80 23.80 2.27 21.83 21.83 2.45 19.76 19.76 2.63
1750
72 33.75 22.32 1.77 31.26 21.46 1.96 28.76 20.59 2.14 26.21 19.77 2.32 23.62 18.89 2.50 20.93 17.97 2.69
67 30.57 29.57 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
63†† 28.24 28.00 1.77 26.35 26.35 1.95 24.49 24.49 2.12 22.60 22.60 2.28 20.66 20.66 2.46 18.62 18.62 2.63
62 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.45 24.45 2.31 22.40 22.40 2.49 20.23 20.23 2.67
57 30.27 30.27 1.77 28.38 28.38 1.95 26.46 26.46 2.13 24.46 24.46 2.31 22.39 22.39 2.49 20.23 20.23 2.67
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CK5A/CK5BW 048 1.00 1.01 CE3AA 48 1.00 1.06
CK5A/CK5BX 060 1.00 0.99 060 1.00 1.04
CK5PA 048 1.00 1.01 CK3BA 048 1.00 1.05
060 1.00 1.00 060 1.00 1.04
CK5PT 048 1.00 1.02 CK5A/CK5BA 048 1.00 1.05
060 1.00 1.00 060 1.00 1.04
CK5PW 048 1.00 1.01 CK5A/CK5BT 048 1.00 1.05
CK5PX 060 1.00 0.99 060 1.00 1.04
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE CK5A/CK5BW 048 1.00 1.05
CC5A/CD5AA 060 1.00 1.02 CK5PA 048 1.00 1.05
CC5A/CD5AC 048 1.00 1.03 060 1.00 1.04
CC5A/CD5AW 048 1.00 1.02 CK5PT 48 1.00 1.05
060 1.00 1.00 060 1.00 1.04
CD5AA 048 1.00 1.02 CK5PW 048 1.00 1.05
CE3AA 048 1.00 1.02
COILS + 355MAV060100 VARIABLE SPEED FURNACE
060 1.00 1.00 CC5A/CD5AA 060 1.00 1.05
CK3BA 048 1.00 1.01 CC5A/CD5AC 048 0.99 1.06
060 1.00 0.99 CC5A/CD5AW 048 1.00 1.05
CK5A/CK5BA 048 1.00 1.01 CD5AA 048 1.00 1.05
060 1.00 0.99 CE3AA 048 1.00 1.05
CK5A/CK5BT 048 1.00 1.01 060 1.00 1.03
060 1.00 0.99 CK3BA 048 1.00 1.05
CK5A/CK5BW 048 1.00 1.01 060 1.00 1.03
CK5A/CK5BX 060 1.00 0.99 CK5A/CK5BA 048 1.00 1.05
CK5PA 048 1.00 1.01 060 1.00 1.03
060 1.00 0.99 CK5A/CK5BT 048 1.00 1.05
CK5PT 048 1.00 1.01 060 1.00 1.03
060 1.00 0.99 CK5A/CK5BW 048 1.00 1.04
CK5PW 048 1.00 1.01 CK5PA 048 1.00 1.05
CK5PX 060 1.00 0.99 060 1.00 1.03
COILS + 355MAV060080 VARIABLE SPEED FURNACE CK5PT 048 1.00 1.05
CC5A/CD5AA 060 1.00 1.06 060 1.00 1.03
CC5A/CD5AC 048 0.99 1.06 CK5PW 048 1.00 1.04
CC5A/CD5AW 048 1.00 1.06
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CD5AA 048 1.00 1.06 CC5A/CD5AA 060 1.00 1.05
