DETAILED COOLING CAPACITIES* continued
See notes on page 37.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX060-C Outdoor Section With FV4BNB006 Indoor Section - Low Speed
1050
72 39.02 21.16 1.92 35.81 19.95 2.10 32.58 18.77 2.28 29.35 17.61 2.45 26.10 16.45 2.61 22.77 15.30 2.77
67 34.93 26.32 1.91 32.03 25.08 2.08 29.04 23.90 2.24 26.12 22.73 2.40 23.23 21.56 2.55 20.35 20.34 2.70
63†† 32.03 25.19 1.89 29.24 23.94 2.06 26.54 22.74 2.21 23.84 21.60 2.36 21.21 20.45 2.51 18.76 18.76 2.65
62 31.45 31.29 1.89 29.23 29.23 2.06 27.08 27.08 2.22 24.92 24.92 2.38 22.70 22.70 2.55 20.35 20.35 2.70
57 31.37 31.37 1.89 29.22 29.22 2.06 27.08 27.08 2.22 24.90 24.90 2.38 22.68 22.68 2.54 20.35 20.35 2.70
1350
72 40.53 23.56 1.96 37.05 22.31 2.15 33.59 21.09 2.33 30.15 19.89 2.50 26.70 18.70 2.67 23.18 17.51 2.83
67 36.34 30.17 1.95 33.19 28.82 2.13 30.00 27.61 2.29 26.96 26.33 2.46 24.39 24.18 2.63 21.59 21.59 2.78
63†† 33.31 28.78 1.93 30.37 27.48 2.11 27.47 26.22 2.27 24.93 24.38 2.42 22.36 22.36 2.57 19.90 19.90 2.73
62 34.08 34.08 1.94 31.67 31.67 2.12 29.22 29.22 2.29 26.76 26.76 2.45 24.25 24.25 2.62 21.59 21.59 2.78
57 34.08 34.08 1.94 31.67 31.67 2.12 29.21 29.21 2.29 26.77 26.77 2.45 24.24 24.24 2.62 21.59 21.59 2.78
1650
72 41.45 25.78 2.00 37.81 24.50 2.19 34.19 23.26 2.37 30.61 22.03 2.55 27.03 20.82 2.71 23.37 19.59 2.88
67 37.24 33.68 1.99 33.94 32.30 2.17 30.79 30.74 2.34 28.11 28.10 2.51 25.34 25.34 2.68 22.45 22.45 2.85
63†† 34.20 32.09 1.98 31.16 30.62 2.15 28.47 28.47 2.32 25.94 25.94 2.48 23.58 23.04 2.65 20.68 20.68 2.80
62 36.09 36.09 1.98 33.43 33.43 2.17 30.88 30.85 2.35 28.08 28.08 2.51 25.34 25.34 2.68 22.45 22.45 2.85
57 36.09 36.09 1.98 33.43 33.43 2.17 30.77 30.77 2.34 28.03 28.03 2.51 25.33 25.33 2.68 22.44 22.44 2.85
1950
72 42.05 27.84 2.03 38.30 26.53 2.23 34.58 25.28 2.42 30.90 24.03 2.59 27.20 22.77 2.76 23.48 21.47 2.92
67 37.94 36.85 2.03 34.80 34.72 2.22 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
63†† 34.96 34.82 2.02 32.20 32.20 2.20 29.49 29.49 2.37 26.80 26.80 2.53 24.05 24.05 2.69 21.21 21.21 2.85
62 37.60 37.60 2.03 34.77 34.77 2.21 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
57 37.60 37.60 2.03 34.77 34.77 2.21 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
2250
72 42.47 29.81 2.07 38.62 28.50 2.27 34.83 27.22 2.46 31.06 25.93 2.63 27.32 24.61 2.80 23.58 23.13 2.96
67 38.80 38.80 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.80 29.80 2.62 26.71 26.71 2.79 23.47 23.47 2.96
63†† 36.00 35.99 2.06 33.12 33.12 2.24 30.28 30.28 2.41 27.47 27.46 2.58 24.57 24.57 2.74 21.60 21.60 2.91
62 38.80 38.80 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.80 29.80 2.62 26.72 26.72 2.79 23.48 23.48 2.96
57 38.81 38.81 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.81 29.80 2.62 26.71 26.71 2.79 23.48 23.48 2.96
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CC5A/CD5AA 060 0.93 1.14 CK5A/CK5BX 060 0.98 0.99
CC5A/CD5AW 060 0.95 1.14 CK5PA 060 0.97 0.99
CE3AA 060 0.95 1.14 CK5PT 060 0.97 0.99
CK3BA 060 0.95 1.14 CK5PX 060 0.98 0.99
CK5A/CK5BA 060 0.95 1.14
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
CK5A/CK5BT 060 0.95 1.14 CC5A/CD5AA 060 0.95 0.98
CK5A/CK5BX 060 0.96 1.14 CC5A/CD5AW 060 0.97 0.98
CK5PA 060 0.95 1.14 CE3AA 060 0.97 0.98
CK5PT 060 0.95 1.14 CK3BA 060 0.97 0.98
CK5PX 060 0.96 1.14 CK5A/CK5BA 060 0.97 0.98
FE4ANB 006 1.00 1.00 CK5A/CK5BT 060 0.97 0.98
FV4BNB 006 1.00 1.00 CK5A/CK5BX 060 0.98 0.99
40FKB/FK4DNB 006 1.00 1.00 CK5PA 060 0.97 0.98
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE CK5PT 060 0.97 0.98
CC5A/CD5AA 060 0.95 0.99 CK5PX 060 0.98 0.99
CE3AA 060 0.97 1.00
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK3BA 060 0.97 0.99 CC5A/CD5AA 060 0.93 1.01
CK5A/CK5BA 060 0.97 0.99 CD5PX 060 0.97 1.02
CK5A/CK5BT 060 0.97 0.99 CE3AA 060 0.96 1.02
CK5A/CK5BX 060 0.98 0.99 CK3BA 060 0.96 1.02
CK5PA 060 0.97 0.99 CK5A/CK5BA 060 0.96 1.02
CK5PT 060 0.97 0.99 CK5A/CK5BT 060 0.96 1.02
CK5PX 060 0.98 0.99 CK5A/CK5BX 060 0.97 1.02
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE CK5PA 060 0.96 1.02
CC5A/CD5AA 060 0.95 0.99 CK5PT 060 0.96 1.02
CC5A/CD5AW 060 0.97 0.99 CK5PX 060 0.97 1.02
CE3AA 060 0.97 0.99
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK3BA 060 0.97 0.99 CC5A/CD5AA 060 0.93 1.01
CK5A/CK5BA 060 0.97 0.99 CD5PX 060 0.97 1.01
CK5A/CK5BT 060 0.97 0.99 CE3AA 060 0.96 1.02
