—37—
DETAILED COOLING CAPACITIES* continued
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240-94. If additional tubing length and/or
indoor unit is located above outdoor unit, a slight variation in capacity may occur.
†Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
‡ Sensible capacities shown are based on 80°F entering air at the indoor coil. For sensible capacities at other than 80°F, deduct 835 Btuh per 1000 CFM of
indoor coil air for each degree below 80°F, or add 835 Btuh per 1000 CFM of indoor coil air per degree above 80°F.
** System kW is total of indoor and outdoor unit kilowatts.
†† TVA rating indoor condition at 75°F dry bulb temperature. All other indoor air temperatures are at 80°F dry bulb.
EWB — Entering Wet Bulb temperature
CFM — Indoor airflow in cubic feet per minute
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
698BNX060-C Outdoor Section With FV4BNB006 Indoor Section - Low Speed continued
1050
72 39.02 21.16 1.92 35.81 19.95 2.10 32.58 18.77 2.28 29.35 17.61 2.45 26.10 16.45 2.61 22.77 15.30 2.77
67 34.93 26.32 1.91 32.03 25.08 2.08 29.04 23.90 2.24 26.12 22.73 2.40 23.23 21.56 2.55 20.35 20.34 2.70
63†† 32.03 25.19 1.89 29.24 23.94 2.06 26.54 22.74 2.21 23.84 21.60 2.36 21.21 20.45 2.51 18.76 18.76 2.65
62 31.45 31.29 1.89 29.23 29.23 2.06 27.08 27.08 2.22 24.92 24.92 2.38 22.70 22.70 2.55 20.35 20.35 2.70
57 31.37 31.37 1.89 29.22 29.22 2.06 27.08 27.08 2.22 24.90 24.90 2.38 22.68 22.68 2.54 20.35 20.35 2.70
1350
72 40.53 23.56 1.96 37.05 22.31 2.15 33.59 21.09 2.33 30.15 19.89 2.50 26.70 18.70 2.67 23.18 17.51 2.83
67 36.34 30.17 1.95 33.19 28.82 2.13 30.00 27.61 2.29 26.96 26.33 2.46 24.39 24.18 2.63 21.59 21.59 2.78
63†† 33.31 28.78 1.93 30.37 27.48 2.11 27.47 26.22 2.27 24.93 24.38 2.42 22.36 22.36 2.57 19.90 19.90 2.73
62 34.08 34.08 1.94 31.67 31.67 2.12 29.22 29.22 2.29 26.76 26.76 2.45 24.25 24.25 2.62 21.59 21.59 2.78
57 34.08 34.08 1.94 31.67 31.67 2.12 29.21 29.21 2.29 26.77 26.77 2.45 24.24 24.24 2.62 21.59 21.59 2.78
1650
72 41.45 25.78 2.00 37.81 24.50 2.19 34.19 23.26 2.37 30.61 22.03 2.55 27.03 20.82 2.71 23.37 19.59 2.88
67 37.24 33.68 1.99 33.94 32.30 2.17 30.79 30.74 2.34 28.11 28.10 2.51 25.34 25.34 2.68 22.45 22.45 2.85
63†† 34.20 32.09 1.98 31.16 30.62 2.15 28.47 28.47 2.32 25.94 25.94 2.48 23.58 23.04 2.65 20.68 20.68 2.80
62 36.09 36.09 1.98 33.43 33.43 2.17 30.88 30.85 2.35 28.08 28.08 2.51 25.34 25.34 2.68 22.45 22.45 2.85
57 36.09 36.09 1.98 33.43 33.43 2.17 30.77 30.77 2.34 28.03 28.03 2.51 25.33 25.33 2.68 22.44 22.44 2.85
1950
72 42.05 27.84 2.03 38.30 26.53 2.23 34.58 25.28 2.42 30.90 24.03 2.59 27.20 22.77 2.76 23.48 21.47 2.92
67 37.94 36.85 2.03 34.80 34.72 2.22 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
63†† 34.96 34.82 2.02 32.20 32.20 2.20 29.49 29.49 2.37 26.80 26.80 2.53 24.05 24.05 2.69 21.21 21.21 2.85
62 37.60 37.60 2.03 34.77 34.77 2.21 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
57 37.60 37.60 2.03 34.77 34.77 2.21 31.94 31.94 2.39 29.06 29.06 2.57 26.12 26.12 2.74 23.05 23.05 2.91
2250
72 42.47 29.81 2.07 38.62 28.50 2.27 34.83 27.22 2.46 31.06 25.93 2.63 27.32 24.61 2.80 23.58 23.13 2.96
67 38.80 38.80 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.80 29.80 2.62 26.71 26.71 2.79 23.47 23.47 2.96
63†† 36.00 35.99 2.06 33.12 33.12 2.24 30.28 30.28 2.41 27.47 27.46 2.58 24.57 24.57 2.74 21.60 21.60 2.91
62 38.80 38.80 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.80 29.80 2.62 26.72 26.72 2.79 23.48 23.48 2.96
57 38.81 38.81 2.07 35.82 35.82 2.26 32.82 32.82 2.44 29.81 29.80 2.62 26.71 26.71 2.79 23.48 23.48 2.96
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Low Speed
Indoor
Section Size
Low Speed
Capacity Power Capacity Power
CK3BA 060 0.96 1.02 CD5PX 060 0.97 1.01
CK5A/CK5BA 060 0.96 1.01 CE3AA 060 0.96 1.01
CK5A/CK5BT 060 0.96 1.01 CK3BA 060 0.96 1.01
CK5A/CK5BX 060 0.97 1.02 CK5A/CK5BA 060 0.96 1.01
CK5PA 060 0.96 1.01 CK5A/CK5BT 060 0.96 1.01
CK5PT 060 0.96 1.01 CK5A/CK5BX 060 0.97 1.01
CK5PX 060 0.97 1.02 CK5PA 060 0.96 1.01
COILS + 355MAV060120 VARIABLE SPEED FURNACE CK5PT 060 0.96 1.01
CC5A/CD5AA 060 0.93 1.00 CK5PX 060 0.97 1.01
