Bryant 698B - HEAT PUMP HEATING PERFORMANCE; OUTDOOR COIL ENTERING AIR TEMPERATURES °F

—38—
HEAT PUMP HEATING PERFORMANCE
See notes on page 56.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡
698BNX024-B Outdoor Section With FV4BNF002000 Indoor Section - High Speed
65
600 6.16 5.67 1.11 8.70 8.00 1.23 11.39 10.38 1.35 14.28 12.68 1.48 17.55 15.97 1.63 21.03 21.03 1.79 25.05 25.05 1.98 29.71 29.71 2.20
700 6.41 5.90 1.13 8.98 8.26 1.25 11.68 10.65 1.35 14.74 13.09 1.49 18.04 16.42 1.62 21.57 21.57 1.78 25.69 25.69 1.98 29.98 29.98 2.13
800 6.57 6.04 1.14 9.19 8.45 1.26 11.95 10.89 1.36 15.05 13.37 1.49 18.37 16.72 1.62 21.92 21.92 1.78 26.13 26.13 1.95 29.19 29.19 2.07
900 6.71 6.17 1.16 9.36 8.60 1.27 12.16 11.09 1.37 15.30 13.59 1.50 18.58 16.91 1.63 22.14 22.14 1.79 26.04 26.04 1.93 28.38 28.38 2.03
70
600 5.62 5.17 1.12 8.16 7.50 1.25 10.81 9.85 1.37 13.65 12.12 1.51 16.87 15.35 1.66 20.31 20.31 1.82 24.26 24.26 2.02 28.81 28.81 2.25
700 5.79 5.33 1.13 8.41 7.73 1.26 11.11 10.13 1.38 14.05 12.48 1.51 17.38 15.81 1.65 20.88 20.88 1.82 24.86 24.86 2.01 29.50 29.50 2.19
800 5.94 5.46 1.15 8.62 7.92 1.27 11.38 10.37 1.39 14.36 12.76 1.51 17.72 16.13 1.66 21.23 21.23 1.82 25.33 25.33 2.02 29.04 29.04 2.13
900 6.07 5.59 1.16 8.85 8.13 1.29 11.60 10.57 1.40 14.63 12.99 1.52 17.98 16.36 1.66 21.46 21.46 1.82 25.59 25.59 1.98 28.41 28.41 2.10
75
600 4.97 4.58 1.12 7.55 6.94 1.26 10.23 9.33 1.39 12.99 11.54 1.53 16.15 14.70 1.68 19.59 19.59 1.86 23.45 23.45 2.05 27.91 27.91 2.29
700 5.14 4.73 1.13 7.74 7.11 1.27 10.53 9.60 1.40 13.41 11.91 1.53 16.69 15.19 1.68 20.14 20.14 1.85 24.10 24.10 2.04 28.75 28.75 2.25
800 5.29 4.87 1.15 8.00 7.35 1.28 10.78 9.83 1.41 13.73 12.20 1.54 17.06 15.52 1.69 20.53 20.53 1.85 24.54 24.54 2.05 28.80 28.80 2.20
900 5.43 4.99 1.16 8.16 7.50 1.30 10.98 10.01 1.42 13.96 12.40 1.54 17.33 15.77 1.69 20.78 20.78 1.86 24.88 24.88 2.04 28.30 28.30 2.17
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Size High Speed Indoor
Section
Size High Speed
Capacity Power Capacity Power
CC5A/CD5AA 024 0.97 1.12 CK5A/CK5BA 024 0.96 1.07
030 0.96 1.13 030 0.96 1.07
036 1.00 1.11 036 0.96 1.07
CC5A/CD5AW 024 0.97 1.12 CK5A/CK5BT 036 0.96 1.07
030 0.96 1.13 CK5A/CK5BW 024 0.96 1.07
036 1.00 1.11 030 1.01 1.04
CE3AA 024 0.98 1.11 CK5PA 024 0.94 0.99
030 1.00 1.10 030 0.94 0.99
036 0.99 1.11 036 0.94 0.98
CF5AA 024 0.98 1.11 CK5PT 036 0.94 0.98
036 1.00 1.12 CK5PW 024 0.94 0.99
CK3BA 024 1.01 1.09 030 0.94 0.98
030 0.98 1.12
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE
036 1.00 1.10 CC5A/CD5AA 024 0.96 1.07
CK5A/CK5BA 024 1.01 1.09 030 0.96 1.06
030 0.98 1.11 036 0.96 1.06
036 1.01 1.10 CC5A/CD5AW 024 0.96 1.06
CK5A/CK5BT 036 1.01 1.10 030 0.96 1.06
CK5A/CK5BW 024 1.01 1.09 036 0.96 1.06
030 0.98 1.11 CE3AA 024 0.96 1.06
036 1.01 1.10 030 0.96 1.06
CK5PA 024 1.01 1.09 036 0.96 1.06
030 0.98 1.11 CK3BA 024 0.95 1.05
036 1.01 1.10 030 0.96 1.06
CK5PT 036 1.01 1.10 036 0.96 1.06
CK5PW 024 1.01 1.09 CK5A/CK5BA 024 0.96 1.07
030 0.98 1.11 030 0.96 1.07
036 1.01 1.10 036 0.96 1.06
FE4ANF 002 1.00 1.00 CK5A/CK5BT 036 0.96 1.06
003 0.98 1.00 CK5A/CK5BW 024 0.96 1.07
FK4DNF 001 0.98 1.02 030 0.96 1.06
FV4BNF 002 1.00 1.00 036 0.96 1.06
003 0.98 1.00 CK5PA 024 0.94 0.98
40FKB/FK4DNF 002 1.00 1.00 030 0.94 0.98
003 0.98 1.00 036 0.94 0.98
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE CK5PT 036 0.94 0.98
CC5A/CD5AA 024 0.96 1.07 CK5PW 024 0.94 0.98
030 0.96 1.07 030 0.94 0.98
036 0.96 1.00 036 0.94 0.97
CC5A/CD5AW 024 0.96 1.07
COILS + 355MAV042040 VARIABLE SPEED FURNACE
030 0.96 1.07 CC5A/CD5AW 036 0.91 0.99
CE3AA 024 0.97 1.06 CE3AA 024 1.02 1.11
030 0.96 1.07 030 1.01 1.06
036 0.96 1.07 036 0.98 1.03
CK3BA 024 0.93 1.01 CK5A/CK5BW 036 1.00 1.03
030 0.94 1.03 CK5PW 036 1.00 1.03
036 0.96 1.07 — — —
