—39—
HEAT PUMP HEATING PERFORMANCE continued
See notes on page 56.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37475767
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡ Total Int* kW‡
698BNX024-B Outdoor Section With FV4BNF002000 Indoor Section - High Speed continued
65
600 6.16 5.67 1.11 8.70 8.00 1.23 11.39 10.38 1.35 14.28 12.68 1.48 17.55 15.97 1.63 21.03 21.03 1.79 25.05 25.05 1.98 29.71 29.71 2.20
700 6.41 5.90 1.13 8.98 8.26 1.25 11.68 10.65 1.35 14.74 13.09 1.49 18.04 16.42 1.62 21.57 21.57 1.78 25.69 25.69 1.98 29.98 29.98 2.13
800 6.57 6.04 1.14 9.19 8.45 1.26 11.95 10.89 1.36 15.05 13.37 1.49 18.37 16.72 1.62 21.92 21.92 1.78 26.13 26.13 1.95 29.19 29.19 2.07
900 6.71 6.17 1.16 9.36 8.60 1.27 12.16 11.09 1.37 15.30 13.59 1.50 18.58 16.91 1.63 22.14 22.14 1.79 26.04 26.04 1.93 28.38 28.38 2.03
70
600 5.62 5.17 1.12 8.16 7.50 1.25 10.81 9.85 1.37 13.65 12.12 1.51 16.87 15.35 1.66 20.31 20.31 1.82 24.26 24.26 2.02 28.81 28.81 2.25
700 5.79 5.33 1.13 8.41 7.73 1.26 11.11 10.13 1.38 14.05 12.48 1.51 17.38 15.81 1.65 20.88 20.88 1.82 24.86 24.86 2.01 29.50 29.50 2.19
800 5.94 5.46 1.15 8.62 7.92 1.27 11.38 10.37 1.39 14.36 12.76 1.51 17.72 16.13 1.66 21.23 21.23 1.82 25.33 25.33 2.02 29.04 29.04 2.13
900 6.07 5.59 1.16 8.85 8.13 1.29 11.60 10.57 1.40 14.63 12.99 1.52 17.98 16.36 1.66 21.46 21.46 1.82 25.59 25.59 1.98 28.41 28.41 2.10
75
600 4.97 4.58 1.12 7.55 6.94 1.26 10.23 9.33 1.39 12.99 11.54 1.53 16.15 14.70 1.68 19.59 19.59 1.86 23.45 23.45 2.05 27.91 27.91 2.29
700 5.14 4.73 1.13 7.74 7.11 1.27 10.53 9.60 1.40 13.41 11.91 1.53 16.69 15.19 1.68 20.14 20.14 1.85 24.10 24.10 2.04 28.75 28.75 2.25
800 5.29 4.87 1.15 8.00 7.35 1.28 10.78 9.83 1.41 13.73 12.20 1.54 17.06 15.52 1.69 20.53 20.53 1.85 24.54 24.54 2.05 28.80 28.80 2.20
900 5.43 4.99 1.16 8.16 7.50 1.30 10.98 10.01 1.42 13.96 12.40 1.54 17.33 15.77 1.69 20.78 20.78 1.86 24.88 24.88 2.04 28.30 28.30 2.17
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Size High Speed Indoor
Section
Size High Speed
Capacity Power Capacity Power
COILS + 355MAV042060 VARIABLE SPEED FURNACE CK5PW 024 1.05 1.08
CC5A/CD5AA 024 1.00 1.11 030 1.00 1.06
030 0.98 1.07 036 1.00 1.02
036 0.91 0.99
COILS + 355MAV042080 VARIABLE SPEED FURNACE
CC5A/CD5AW 024 1.00 1.11 CC5A/CD5AA 036 0.91 0.99
030 0.98 1.07 CC5A/CD5AW 024 1.00 1.10
036 0.90 0.98 030 0.98 1.07
CE3AA 024 1.01 1.10 036 0.92 1.00
030 1.01 1.06 CE3AA 024 1.02 1.11
036 1.00 1.05 030 1.01 1.06
CK3BA 024 1.05 1.07 036 0.98 1.03
030 1.00 1.05 CK3BA 024 1.05 1.07
036 1.00 1.02 030 1.00 1.05
CK5A/CK5BA 024 1.05 1.08 036 1.00 1.03
030 1.00 1.06 CK5A/CK5BA 036 1.00 1.03
036 1.00 1.02 CK5A/CK5BT 036 1.00 1.03
CK5A/CK5BT 036 1.00 1.02 CK5A/CK5BW 024 1.05 1.08
CK5A/CK5BW 024 1.05 1.08 030 1.00 1.06
030 1.00 1.06 036 1.00 1.03
036 1.00 1.02 CK5PA 036 1.00 1.03
CK5PA 024 1.05 1.08 CK5PT 036 1.00 1.03
030 1.00 1.06 CK5PW 024 1.05 1.08
036 1.00 1.02 030 1.00 1.06
CK5PT 036 1.00 1.02 036 1.00 1.03
