ITEM PART NO. QTY. DESCRIPTION
1 * --------- 1 WELDMENT MOUNTING BASE
2 075580 1 FLANGE FUEL INLET
3 0E1006 1 ASSY REGULATOR 1.5L N.G.OR LPV
4039253 2 SCREW HHC M8-1.25 X 20 G8.8
5 022145 2 WASHER FLAT 5/16 ZINC
6 022129 6 WASHER LOCK M8-5/16
7 045771 2 NUT HEX M8-1.25 G8 YEL CHR
8 0A7040 1 BRACKET-RAD HOSE
9 032552 1 BARBED EL 90 5/16 X 1/8 NPT
10 029032 1 HOSE 9/32 ID 11"
11 0E1056 1 FUEL HOSE ASSM. NAT.GAS/L.P.V.
12 029032 1 HOSE 9/32 ID 6.5"
13 0A5547 1 COVER AIR CLEANER
14 048031C 4 CLAMP HOSE BAND 1/4
15 0D1509 1 DECAL INLET PRESSURE
16 ** 0E0591 1 ADAPTER,CARB.TO AIR CLNR
17 059402 1 FILTER ELEMENT
18 037561 1 NUT WING 1/4-20 NYLK
19 0E1028 1 CARBURETOR ASSY. 1.5L
20 059401 1 CARBURETOR GASKET
21 ** 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
22 ** 049226 4 WASHER LOCK M5
23 026307 1 ELBOW 90D STREET 3/4
24 062522 1 STUD TH 1/4-20 X 3 G2 ZNC FULL
25 022127 1 NUT HEX 1/4-20 STEEL
26 022259 2 NUT HEX 5/16-18 STEEL
27 050279 1 DECAL FUEL INLET NG
28 0A6125 2 STUD 5/16-18 X 1.25 F THR
29 0D8492T 1 DECAL EMISSION CTRL 1.5 NG 2005 (10-15KW NATURAL GAS)
30 ** 0E1104 1 GASKET AIR CLEANER ADAPTER
31 ** 0E0668 1 O-RING 2-028 1.38 X 1.50 X .06
32 ** 0E0590 1 VENTURI 18MM
33 ** 0C5133 1 O-RING 29.82 X 2.62
34 ** 0E0665 1 SCREW THROTTLE PIN STOP
35 ** 0E1108 1 THROTTLE ARM REWORK
36 ** 033138 1 SCREW HHM #10-32 X 5/8
37 ** 022152 1 WASHER LOCK #10
38 ** 0E0645 1 LEVER THROTTLE STOP
39 ** 063463A 1 BARBED STR 3/8NPT X 1/2 W/VS
40 0E1558 1 HOSE LPG & NAT GAS 1/2 ID (23"LG)
41 057823 2 CLAMP HOSE #10 .56 - 1.06
42 0E1111 1 PLATE, GAS REGULATOR MOUNTING
43 042907 2 SCREW HHC M8-1.25 X 16 G8.8
44 0C2454 2 SCREW TH-FRM M6-1 X 16 N WA Z/JS
* SHOWN IN OTHER VIEW
** INCLUDED IN ITEM 19 (CARBURETOR ASY. )
Section 9 - Exploded Views and Parts
Bryant Liquid-cooled 15 kW Generators
Fuel System — Drawing No. 0E0774-E
