18
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
186BNA060000BAAA
30
( --- 1.11)
TCG 45.10 43.80 42.30 40.50 38.50 36.20 33.50 30.50
SDT 69.00 78.40 87.70 97.10 106.40 115.60 124.80 134.00
KW 2.22 2.52 2.83 3.17 3.56 4.00 4.53 5.15
35
(1.67)
TCG 50.00 48.40 46.70 44.70 42.50 40.00 37.10 33.80
SDT 70.40 79.70 89.00 98.20 107.40 116.60 125.80 134.90
KW 2.21 2.52 2.85 3.19 3.58 4.03 4.55 5.16
40
(4.44)
TCG 55.10 53.40 51.40 49.20 46.70 44.00 40.80 37.30
SDT 71.90 81.10 90.20 99.40 108.50 117.60 126.70 135.70
KW 2.21 2.53 2.86 3.21 3.61 4.05 4.57 5.18
45
(7.22)
TCG 60.70 58.60 56.40 54.00 51.20 48.20 44.80 41.00
SDT 73.50 82.50 91.60 100.70 109.70 118.70 127.70 136.70
KW 2.20 2.53 2.87 3.23 3.63 4.08 4.60 5.20
50
(10.0)
TCG 66.50 64.20 61.70 59.00 56.00 52.60 48.90 44.70
SDT 75.10 84.00 93.00 102.00 111.00 119.90 128.80 137.60
KW 2.19 2.53 2.89 3.26 3.66 4.11 4.63 5.22
55
(12.78)
TCG 72.80 70.10 67.30 64.20 60.90 57.20 53.10 48.60
SDT 76.80 85.70 94.50 103.40 112.30 121.10 129.90 138.60
KW 2.18 2.54 2.90 3.28 3.69 4.15 4.66 5.25
186BNA061000BAAA
30
( --- 1.11)
TCG 47.40 46.30 45.00 43.40 41.50 39.30 36.80 33.80
SDT 70.70 80.00 89.20 98.50 107.70 116.90 126.00 135.10
KW 1.95 2.35 2.79 3.30 3.90 4.61 5.45 6.46
35
(1.67)
TCG 52.30 51.10 49.60 47.90 45.90 43.40 40.70 37.40
SDT 72.20 81.40 90.60 99.70 108.90 118.00 127.00 136.00
KW 1.98 2.38 2.82 3.34 3.94 4.65 5.49 6.49
40
(4.44)
TCG 57.60 56.20 54.60 52.70 50.40 47.80 44.80 41.20
SDT 73.90 82.90 92.00 101.00 110.10 119.10 128.10 137.00
KW 2.01 2.41 2.86 3.38 3.99 4.70 5.54 6.53
45
(7.22)
TCG 63.20 61.70 59.90 57.80 55.30 52.40 49.00 45.20
SDT 75.60 84.50 93.50 102.50 111.40 120.40 129.20 138.10
KW 2.05 2.45 2.91 3.43 4.04 4.75 5.59 6.58
50
(10.0)
TCG 69.20 67.50 65.50 63.20 60.40 57.20 53.50 49.40
SDT 77.40 86.20 95.10 104.00 112.80 121.70 130.40 139.10
KW 2.09 2.50 2.96 3.49 4.10 4.82 5.65 6.64
55
(12.78)
TCG 75.60 73.70 71.40 68.80 65.70 62.20 58.20 53.60
SDT 79.30 88.00 96.80 105.60 114.30 123.00 131.70 140.30
KW 2.14 2.56 3.03 3.56 4.17 4.89 5.72 6.70
* A HRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F/° C)
SST --- Saturated Temperature Entering Compressor (° F)
TCG --- Gross Cooling Capacity (1000 Btuh)
