Bryant EVOLUTION 16 186B - Accessory Usage Guideline

5
ACCESSORIES
KIT NUMBER KIT NAME 018--- A 024--- A 030 --- A 036--- A 042--- A 048--- A 060--- A 061--- A
KAACH1701AAA CRANKCASE HTR X X X X
KAACH1601AAA CRANKCASE HTR X
STANDARD CRANKCASE HTR S S S
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X X
KSAHS2701AAA HARD START (CAP/RELA Y ) X X X X X X X X
KSALA0301410
L O W --- A MB I E N T P R E S S U R E
SWITCH
X X X X X X X X
KAACS0201PTC PT C START ASSIST X X X X X X X X
KAALS0201LLS SOLENOID VALVE X X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X X
KAATD0101TDR TIME DELAY X X X X X X X X
KSATX0201PUR TXV (HSO) X X X
KSATX0301PUR TXV (HSO) X
KSATX0401PUR TXV (HSO) X
KSATX0501PUR TXV (HSO) X X X
KAAWS0101AAA WINTER START X X X X X X X X
X = Accessory, S = Standard
ACCESSORY CONTROLS
EVOLUTION C ONTROLS
DESCRIPTION
SYSTXBBUID01 --- D Evolution Control Deluxe 7---Day Programmable (Wall---mounted system control.)
SYSTXBBUIZ01--- D Evolution Control Deluxe Zoning 7---Day Programmable (Wall---mounted control for a multi ---zone system.)
SYSTXBB4ZC01 Evolution 4---Zone Damper Control Module (Wall--- mounted control for a four---zone system.)
SYSTXBBSMS01 Evolution Smart Sensor (Optional wall control used to monitor temperature and/or fan control in an individual zone.)
SYSTXBBRRS01 Evolution Remote Room Sensor (Monitors temperature in an individual zone.)
SYSTXBBRWF01 Evolution Sy stem Access Module (Hardware for wireless access and control via phone or internet.)
SYSTXBBNIM01
Evolution Network Interface Module (Connects Heat Recovery and Energy Recovery Ventilators on non---zoning applica-
tions.)
SYSTXBBLBPU01 --- C Decorative Back Plate for Evolu tion C ontrol (Decorative wall plate.)
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW---AMBI-
ENT COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR LONG
LINE
APPLICATIONS*
(Over 80 ft./24.38 m)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within2miles/3.22km)
Compressor Start Assist Capacitor and Relay Yes Yes No
Crankcase H eater Yes Yes No
Evaporator Freeze Thermostat Yes No No
H a r d S h u t --- O f f T X V Yes Yes Yes
Liquid Line Solenoid Valve No No No
L o w --- a m b i e n t P r e s s u r e S w i t c h Yes No No
Support Feet Recommended No Recommended
Winter Start Control Yes No No
* For tubing line sets between 80 an d 200 ft. ( 24.38 and 60.96 m) and/or 35 f t. (10.7 m) vertical differential, refer to Residential Piping and Lon gline Guideline.
{ Required for Low---Ambient Controller (full modulation feature) MotorMasterr Control.
186B
