Bryant EVOLUTION 16 186B User Manual

7
ELECTRICAL DATA
U N I T S I Z E ---
SERIES
V/PH
OPER VOLTS* COMPR FAN
MCA
MIN
WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
ft (m)}
MAX
LENGTH
ft (m)}
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C
018--- A
208/230/1 253 197
48.0 9.0 0.5 11.8 14 14 66 (20.12) 62 (18.90) 20
024--- A 58.3 13.5 0.7 17.6 14 14 44 (13.41) 42 (12.80) 25
030--- A 64.0 12.8 0.7 16.7 14 14 46 (14.02) 44 (13.41) 25
036--- A 77.0 14.1 0.5 18.1 14 14 44 (13.41) 42 (12.80) 30
042--- A 112.0 17.9 1.2 23.6 12 12 52 (15.85) 50 (15.24) 40
048--- A 109.0 19.9 1.2 26.1 10 10 77 (23.47) 73 (22.25) 40
060--- A 135.0 21.4 1.2 28.0 10 10 71 (21.64) 68 (20.73) 40
061--- A 134.0 25.0 1.2 32.5 8 10 94 (28.65) 58 (17.68) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{ If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC ( NFPA 70). The ampacity of non ---metall ic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336---26. If other than u ncoated (no ---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
} Length sh own is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u se .
FLA --- F u l l L o a d Am p s
LRA --- L o c k e d Ro t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER (dBA)
U N I T S I Z E ---
SERIES
STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
018--- A 68 52.5 58.0 62.5 62.5 60.5 58.0 48.5
024--- A 72 56.0 60.5 65.5 66.5 64.5 61.0 52.5
030--- A 72 53.5 62.0 65.0 67.0 61.5 58.0 50.5
036--- A 69 50.5 58.5 63.0 64.0 59.5 57.5 50.5
042--- A 72 57.0 60.5 65.0 66.0 62.5 60.5 55.0
048--- A 73 56.0 61.5 65.0 68.0 63.0 58.5 52.5
060--- A 72 54.5 62.5 66.0 66.0 62.5 62.0 59.0
061--- A 72 54.0 65.0 66.0 67.0 63.0 58.5 52.5
NOTE: Tested in accordance with AHRI Standard 270---08 (not listed in AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- SERIES REQUIRED SUBCOOLING _F(_ C)
018--- A 10 (5.6)
024--- A 10 (5.6)
030--- A 10 (5.6)
036--- A 10 (5.6)
042--- A 9 (5.0)
048--- A 10 (5.6)
060--- A 9 (5.0)
061--- A 10 (5.6)
186B
