Bryant EVOLUTION 16 186B - Page 8

8
DIMENSIONS -- ENGLISH
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE
- 26" X 26"
18,24,30
36,42,48,60,61 35" X 35"
UNIT SERIES
ELECTRICAL
CHARACTERISTICS
ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)
SHIPPING
WEIGHT (lbs)
186B018 A X O O O 31 3/16" 28 11/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 15 1/2" 17" 14 " 175.5 212.5 186B024 A X O O O 31 3/16" 28 11/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 16 1/4" 15 1/4" 14 " 176 211.5 186B030 A X O O O 31 3/16" 32 1/8" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 15" 15 3/4" 14 3/4" 186.5 222.5 186B036 A X O 0 0 35" 30 1/16" 3 7/8" 7/8" 6 9/16" 28 11/16" 9 1/8" 2 15/16" 5/8" 17" 16 3/4" 14 " 200 243 186B042 A X O O O 35" 40 1/4" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17" 16" 18 1/2" 253 297 186B048 A X O 0 0 35" 40 1/4" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 1/2" 16 1/4" 18" 295 340 186B060 A X O 0 0 35" 47 1/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 1/2" 17 1/4" 21" 327 373.5
186B061 A X O O O 35" 47 1/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 1/4" 17" 21" 326 373
X = YES O=NO
NOTES: 1. ALLOW 30" CLEARANCE TO SERVICE SIDE OF UNIT,
48" ABOVE UNIT, 6" ON ONE SIDE, 12" ON REMAINING SIDE, AND 24" BETWEEN UNITS FOR PROPER AIRFLOW.
2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING
MODE IS 55
A
B
C
31/2"
17/8"
P
E
F
N
G
M
L
3"
5/16"
K
SQ.
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY
CONN.
1 1/8" KNOCKOUT
D
AIR DISCHARGE
AIR IN
AIR IN
AIR IN
AIR IN
AIR DISCHARGE
186B
