DETAILED COOLING CAPACITIES# CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Capacity MBtuh
Tot a l
Sys.
KW**
Tot a l Sens} Tot a l Sens} Tot a l Sens} Tot a l Sens} To ta l Sens} Tot a l Sens}
123ANA030 Outdoor Section With 30 Indoor Section
875
72 (22.2) 33.13 17.60 2.01 31.70 17.06 2.23 30.20 16.49 2.47 28.59 15.90 2.75 26.87 15.27 3.06 25.01 14.60 3.38 67 (19.4) 30.12 21.64 2.01 28.78 21.09 2.23 27.37 20.50 2.48 25.87 19.89 2.76 24.27 19.25 3.07 22.59 18.58 3.42 62 (16.7) 27.50 25.68 2.01 26.29 25.09 2.23 25.03 24.47 2.48 23.75 23.75 2.77 22.56 22.56 3.08 21.27 21.27 3.43 57 (13.9) 26.93 26.93 2.01 25.94 25.94 2.24 24.89 24.89 2.48 23.76 23.76 2.77 22.56 22.56 3.08 21.27 21.27 3.43
1000
72 (22.2) 33.69 18.46 2.05 32.21 17.92 2.27 30.64 17.34 2.52 28.98 16.74 2.80 27.20 16.10 3.11 25.32 15.44 3.45 67 (19.4) 30.64 23.04 2.05 29.26 22.48 2.27 27.80 21.89 2.52 26.25 21.27 2.80 24.61 20.61 3.12 22.87 19.92 3.46 62 (16.7) 28.16 27.55 2.06 26.95 26.95 2.28 25.86 25.86 2.53 24.67 24.67 2.81 23.39 23.39 3.12 22.02 22.02 3.47 57 (13.9) 28.03 28.03 2.06 26.98 26.98 2.28 25.86 25.86 2.53 24.67 24.67 2.81 23.39 23.39 3.12 22.02 22.02 3.47
1125
72 (22.2) 34.09 19.27 2.10 32.57 18.72 2.32 30.96 18.14 2.56 29.26 17.54 2.84 27.43 16.89 3.15 25.50 16.22 3.49 67 (19.4) 31.03 24.36 2.10 29.61 23.80 2.32 28.12 23.20 2.57 26.54 22.57 2.85 24.86 21.90 3.16 23.10 21.19 3.50 62 (16.7) 28.94 28.94 2.10 27.83 27.83 2.32 26.66 26.66 2.57 25.40 25.40 2.85 24.06 24.06 3.16 22.61 22.61 3.48 57 (13.9) 28.94 28.94 2.10 27.83 27.83 2.32 26.66 26.66 2.57 25.41 25.41 2.85 24.06 24.06 3.16 22.62 22.62 3.51
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CAP**3014A** 1.00 1.00
CAP**3017A** 1.00 1.00 CAP**3614A** 1.00 1.00 CAP**3617A** 1.00 1.00 CAP**3621A** 1.00 1.00
CNPF*3618A** 0.99 0.99
CNPH*3017A** 0.99 0.99 CNPH*3617A** 0.99 0.99
CNPV*3014A** 0.99 0.99 CNPV*3017A** 0.99 0.99 CNPV*3617A** 0.99 0.99 CNPV*3621A** 0.99 0.99
CSPH*3012A** 0.96 0.96 CSPH*3612A** 0.98 0.98
FE4AN(B,F)003 1.00 0.94 FE4AN(B,F)005 1.03 0.94
FE4ANF002 0.99 0.95 FF1ENP030 0.98 0.98 FF1ENP036 1.00 1.00
FV4BN(B,F)003 1.00 0.94 FV4BN(B,F)005 1.03 0.94
FV4BNF002 0.99 0.95
FX4CN(B,F)036 1.01 0.96
FX4CNF030 1.00 0.98
FY4ANF030 0.99 0.99 FY4ANF036 0.99 0.99
CAP**3014A** 0.99 0.97 315(A,J)AV036070 CAP**3614A** 0.99 0.94 315(A,J)AV036070
CNPH*3017A** 0.98 0.94 315(A,J)AV036070 CNPH*3617A** 0.98 0.94 315(A,J)AV036070
CNPV*3014A** 0.98 0.96 315(A,J)AV036070
CSPH*3012A** 0.96 0.92 315(A,J)AV036070 CSPH*3612A** 0.97 0.93 315(A,J)AV036070
CAP**3017A** 0.99 0.94 315(A,J)AV048090 CAP**3617A** 0.99 0.95 315(A,J)AV048090
CNPV*3017A** 0.98 0.94 315(A,J)AV048090 CNPV*3617A** 0.98 0.94 315(A,J)AV048090
CAP**3621A** 0.99 0.95 315(A,J)AV060110
CNPV*3621A** 0.99 0.94 315(A,J)AV060110
CAP**3017A** 1.00 0.92 353AAV036040 CAP**3617A** 1.00 0.90 353AAV036040
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*3017A** 1.00 0.92 353AAV036040 CNPH*3617A** 1.00 0.92 353AAV036040
CNPV*3017A** 1.00 0.92 353AAV036040 CNPV*3617A** 1.00 0.92 353AAV036040
CSPH*3012A** 1.00 0.92 353AAV036040 CSPH*3612A** 1.00 0.90 353AAV036040
CAP**3017A** 1.00 0.92 353AAV036060 CAP**3617A** 1.00 0.92 353AAV036060
CNPH*3017A** 1.00 0.92 353AAV036060 CNPH*3617A** 1.00 0.92 353AAV036060
CNPV*3017A** 1.00 0.92 353AAV036060 CNPV*3617A** 1.00 0.92 353AAV036060
CSPH*3012A** 1.00 0.92 353AAV036060 CSPH*3612A** 1.00 0.92 353AAV036060
CAP**3017A** 1.00 0.92 353AAV036080 CAP**3617A** 1.00 0.90 353AAV036080
CNPH*3017A** 1.00 0.92 353AAV036080 CNPH*3617A** 1.00 0.92 353AAV036080
CNPV*3017A** 1.00 0.92 353AAV036080 CNPV*3617A** 1.00 0.92 353AAV036080
CSPH*3012A** 1.00 0.92 353AAV036080 CSPH*3612A** 1.00 0.90 353AAV036080
CAP**3017A** 1.00 0.92 353AAV048080 CAP**3617A** 1.00 0.92 353AAV048080
CNPH*3017A** 1.00 0.92 353AAV048080 CNPH*3617A** 1.00 0.92 353AAV048080
CNPV*3017A** 1.00 0.92 353AAV048080 CNPV*3617A** 1.00 0.92 353AAV048080
CSPH*3012A** 1.00 0.92 353AAV048080 CSPH*3612A** 1.00 0.92 353AAV048080
CNPH*3017A** 0.98 0.96 355(A,C)AV042040 CNPH*3617A** 0.98 0.96 355(A,C)AV042040
CSPH*3012A** 0.96 0.94 355(A,C)AV042040 CSPH*3612A** 0.97 0.93 355(A,C)AV042040
CAP**3017A** 0.99 0.94 355(A,C)AV042060 CAP**3617A** 0.99 0.94 355(A,C)AV042060
CNPV*3017A** 0.98 0.94 355(A,C)AV042060 CNPV*3617A** 0.98 0.94 355(A,C)AV042060
CAP**3014A** 0.98 0.96 355(A,C)AV042080 CAP**3621A** 0.99 0.95 355(A,C)AV042080
CNPH*3017A** 0.99 0.94 355(A,C)AV042080
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*3621A** 0.98 0.94 355(A,C)AV042080 CNPV*3621A** 0.99 0.93 355(A,C)AV060080
CAP**3017A** 0.99 0.93 313*AV048070 CAP**3617A** 1.00 0.94 313*AV048070
CNPH*3017A** 0.99 0.93 313*AV048070 CNPH*3617A** 0.99 0.93 313*AV048070
CNPV*3017A** 0.99 0.93 313*AV048070 CNPV*3617A** 0.99 0.93 313*AV048070
CSPH*3012A** 0.99 0.93 313*AV048070 CSPH*3612A** 1.00 0.92 313*AV048070
CAP**3621A** 1.01 0.92 313*AV048090
CNPH*3017A** 0.99 0.91 313*AV048090 CNPH*3617A** 0.99 0.91 313*AV048090
CNPV*3621A** 0.99 0.91 313*AV048090
CSPH*3012A** 0.99 0.93 313*AV048090 CSPH*3612A** 1.01 0.92 313*AV048090
