CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
123A*A018 ---C
30
( ---1.11)
TCG 15.90 15.00 14.10 13.10 12.20 11.20 10.20 9.10
SDT 67.80 77.30 86.80 96.30 105.90 115.50 125.10 134.80
KW 0.80 0.92 1.06 1.20 1.36 1.54 1.73 1.92
35
(1.67)
TCG 17.50 16.50 15.50 14.50 13.50 12.50 11.40 10.20
SDT 68.80 78.20 87.70 97.20 106.70 116.20 125.80 135.40
KW 0.80 0.92 1.05 1.20 1.36 1.54 1.73 1.94
40
(4.44)
TCG 19.20 18.20 17.10 16.00 14.90 13.80 12.60 11.40
SDT 69.80 79.20 88.70 98.10 107.50 117.00 126.50 136.00
KW 0.79 0.91 1.05 1.20 1.36 1.54 1.74 1.95
45
(7.22)
TCG 21.00 19.90 18.80 17.60 16.40 15.20 14.00 12.60
SDT 70.90 80.30 89.70 99.10 108.40 117.80 127.20 136.70
KW 0.79 0.91 1.05 1.20 1.36 1.54 1.74 1.95
50
(10.0)
TCG 22.90 21.70 20.40 19.20 17.90 16.60 15.30 13.90
SDT 72.00 81.40 90.70 100.10 109.30 118.70 128.00 137.30
KW 0.79 0.91 1.04 1.19 1.36 1.54 1.74 1.95
55
(12.78)
TCG 24.80 23.50 22.10 20.80 19.40 18.00 16.70 15.20
SDT 73.10 82.50 91.80 101.10 110.30 119.50 128.80 138.00
KW 0.78 0.90 1.04 1.19 1.36 1.54 1.74 1.95
123A*A024 ---C
30
( ---1.11)
TCG 21.20 20.00 18.80 17.60 16.40 15.10 13.80 12.50
SDT 71.90 81.20 90.60 100.10 109.50 119.00 128.60 138.20
KW 1.04 1.19 1.37 1.56 1.77 2.01 2.26 2.53
35
(1.67)
TCG 23.30 22.10 20.80 19.50 18.20 16.80 15.40 13.90
SDT 73.20 82.50 91.80 101.10 110.50 119.90 129.40 139.00
KW 1.03 1.19 1.37 1.56 1.77 2.01 2.27 2.54
40
(4.44)
TCG 25.60 24.20 22.90 21.50 20.00 18.60 17.10 15.50
SDT 74.60 83.80 93.00 102.30 111.50 120.90 130.30 139.70
KW 1.03 1.19 1.37 1.56 1.78 2.01 2.27 2.55
45
(7.22)
TCG 28.00 26.50 25.00 23.50 22.00 20.40 18.80 17.10
SDT 76.00 85.10 94.30 103.50 112.60 121.90 131.20 140.50
KW 1.03 1.19 1.37 1.56 1.78 2.01 2.27 2.55
50
(10.0)
TCG 30.50 28.90 27.30 25.70 24.00 22.30 20.60 18.80
SDT 77.50 86.60 95.60 104.70 113.80 122.90 132.10 141.20
KW 1.03 1.19 1.37 1.56 1.77 2.01 2.27 2.55
55
(12.78)
TCG 33.00 31.30 29.60 27.80 26.10 24.30 22.40 20.40
SDT 79.00 88.00 97.00 106.00 114.90 124.00 133.00 142.00
KW 1.03 1.19 1.37 1.56 1.77 2.01 2.27 2.55
123A*A030 ---C
30
( ---1.11)
TCG 24.60 23.30 22.00 20.60 19.10 17.70 16.10 14.50
SDT 72.10 81.50 91.00 100.60 110.20 120.00 129.90 139.90
KW 1.33 1.50 1.69 1.91 2.14 2.40 2.67 2.97
35
(1.67)
TCG 27.10 25.70 24.30 22.80 21.30 19.70 18.00 16.20
SDT 73.40 82.70 92.20 101.60 111.20 120.90 130.70 140.60
KW 1.34 1.51 1.70 1.91 2.14 2.40 2.69 3.00
40
(4.44)
TCG 29.80 28.30 26.80 25.20 23.50 21.80 20.00 18.20
SDT 74.70 84.00 93.30 102.70 112.20 121.80 131.50 141.30
KW 1.34 1.51 1.70 1.91 2.15 2.41 2.70 3.01
45
(7.22)
TCG 32.70 31.10 29.40 27.70 26.00 24.10 22.20 20.20
SDT 76.10 85.20 94.50 103.80 113.10 122.70 132.30 142.00
KW 1.35 1.52 1.71 1.92 2.15 2.42 2.71 3.02
50
(10.0)
TCG 35.80 34.10 32.30 30.50 28.60 26.60 24.60 22.40
SDT 77.50 86.60 95.70 104.90 114.20 123.60 133.10 142.60
KW 1.35 1.52 1.71 1.92 2.16 2.42 2.71 3.03
55
(12.78)
TCG 39.10 37.20 35.30 33.40 31.30 29.30 27.10 24.80
SDT 79.00 88.00 97.00 106.10 115.20 124.50 133.90 143.30
KW 1.36 1.53 1.72 1.93 2.16 2.42 2.71 3.03
123A*A036 ---C
30
( ---1.11)
TCG 31.50 29.90 28.20 26.50 24.70 22.80 20.90 18.80
SDT 72.10 81.10 90.20 99.30 108.50 117.70 127.00 136.30
KW 1.62 1.82 2.05 2.31 2.59 2.90 3.23 3.58
35
(1.67)
TCG 34.70 32.90 31.10 29.20 27.30 25.30 23.20 21.00
SDT 73.70 82.50 91.50 100.50 109.60 118.70 127.90 137.10
KW 1.63 1.83 2.06 2.32 2.60 2.91 3.25 3.61
40
(4.44)
TCG 38.10 36.20 34.20 32.20 30.10 27.90 25.70 23.30
SDT 75.30 84.00 92.80 101.80 110.70 119.80 128.90 138.00
KW 1.64 1.84 2.07 2.33 2.62 2.93 3.27 3.63
45
(7.22)
TCG 41.70 39.60 37.50 35.30 33.10 30.70 28.30 25.70
SDT 77.00 85.60 94.30 103.10 112.00 121.00 129.90 138.90
KW 1.65 1.86 2.09 2.34 2.63 2.94 3.28 3.65
50
(10.0)
TCG 45.60 43.30 41.00 38.60 36.20 33.70 31.00 28.20
SDT 78.90 87.30 95.90 104.60 113.30 122.20 131.00 139.90
KW 1.67 1.87 2.10 2.36 2.64 2.96 3.30 3.67
55
(12.78)
TCG 49.60 47.10 44.60 42.00 39.40 36.70 33.80 30.80
SDT 80.80 89.10 97.50 106.10 114.70 123.40 132.10 140.80
KW 1.69 1.89 2.12 2.38 2.66 2.97 3.31 3.68
See n otes on page 36
