36
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
123A*A042 ---C
30
( ---1.11)
TCG 38.00 36.00 33.90 31.90 29.70 27.60 25.30 22.90
SDT 73.20 82.30 91.40 100.60 109.80 119.10 128.40 137.70
KW 1.95 2.20 2.48 2.80 3.14 3.53 3.95 4.41
35
(1.67)
TCG 41.90 39.70 37.40 35.10 32.80 30.50 28.00 25.50
SDT 74.80 83.70 92.80 101.90 111.00 120.20 129.40 138.60
KW 1.97 2.22 2.50 2.81 3.16 3.54 3.97 4.43
40
(4.44)
TCG 46.00 43.60 41.10 38.70 36.20 33.60 30.90 28.10
SDT 76.40 85.20 94.20 103.20 112.20 121.30 130.40 139.50
KW 1.98 2.23 2.52 2.83 3.18 3.56 3.98 4.44
45
(7.22)
TCG 50.30 47.70 45.10 42.40 39.60 36.80 33.90 30.90
SDT 78.10 86.90 95.70 104.60 113.50 122.50 131.40 140.40
KW 2.01 2.26 2.54 2.85 3.19 3.58 4.00 4.45
50
(10.0)
TCG 54.90 52.10 49.20 46.20 43.20 40.20 37.00 33.60
SDT 80.00 88.60 97.20 106.00 114.80 123.70 132.50 141.30
KW 2.03 2.28 2.56 2.87 3.21 3.60 4.01 4.47
55
(12.78)
TCG 59.70 56.60 53.40 50.20 46.90 43.50 40.10 36.40
SDT 81.90 90.30 98.90 107.50 116.20 124.90 133.60 142.20
KW 2.06 2.30 2.58 2.89 3.23 3.62 4.03 4.48
123A*A048 ---C
30
( ---1.11)
TCG 41.60 39.30 37.10 34.80 32.40 30.00 27.40 24.80
SDT 73.90 83.20 92.60 101.90 111.30 120.80 130.20 139.70
KW 2.24 2.54 2.87 3.24 3.64 4.08 4.56 5.08
35
(1.67)
TCG 45.80 43.40 40.90 38.50 35.90 33.30 30.60 27.70
SDT 75.40 84.70 93.90 103.20 112.50 121.90 131.30 140.70
KW 2.25 2.55 2.88 3.25 3.66 4.10 4.59 5.11
40
(4.44)
TCG 50.30 47.70 45.10 42.40 39.60 36.80 33.90 30.90
SDT 77.00 86.20 95.30 104.50 113.80 123.00 132.30 141.60
KW 2.26 2.56 2.89 3.26 3.67 4.12 4.61 5.14
45
(7.22)
TCG 55.10 52.30 49.50 46.60 43.60 40.60 37.50 34.20
SDT 78.60 87.70 96.80 105.90 115.00 124.20 133.40 142.60
KW 2.27 2.57 2.90 3.27 3.68 4.13 4.62 5.15
50
(10.0)
TCG 60.20 57.20 54.20 51.10 47.90 44.60 41.20 37.70
SDT 80.30 89.40 98.40 107.40 116.40 125.50 134.50 143.50
KW 2.28 2.59 2.92 3.29 3.70 4.15 4.64 5.17
55
(12.78)
TCG 65.70 62.50 59.20 55.80 52.40 48.90 45.20 41.30
SDT 82.10 91.10 100.00 108.90 117.80 126.80 135.70 144.50
KW 2.30 2.60 2.94 3.30 3.71 4.16 4.65 5.18
123A*A060 ---C
30
( ---1.11)
TCG 53.30 50.40 47.40 44.50 41.50 38.40 35.20 31.90
SDT 74.40 83.30 92.20 101.30 110.40 119.50 128.60 137.70
KW 2.61 2.94 3.32 3.73 4.20 4.71 5.27 5.88
35
(1.67)
TCG 58.70 55.50 52.20 49.00 45.70 42.30 38.90 35.20
SDT 76.10 84.90 93.70 102.70 111.70 120.70 129.70 138.70
KW 2.65 2.98 3.36 3.77 4.24 4.75 5.31 5.91
40
(4.44)
TCG 64.30 60.80 57.30 53.80 50.20 46.50 42.60 38.60
SDT 78.00 86.60 95.30 104.20 113.00 121.90 130.80 139.60
KW 2.70 3.03 3.40 3.82 4.28 4.79 5.35 5.95
45
(7.22)
TCG 70.30 66.50 62.70 58.80 54.80 50.70 46.50 42.10
SDT 79.90 88.40 97.00 105.70 114.50 123.20 132.00 140.60
KW 2.75 3.08 3.46 3.87 4.33 4.84 5.39 5.99
50
(10.0)
TCG 76.70 72.50 68.20 64.00 59.60 55.20 50.60 45.60
SDT 82.00 90.40 98.80 107.40 116.00 124.60 133.20 141.70
KW 2.81 3.14 3.51 3.93 4.38 4.89 5.44 6.03
55
(12.78)
TCG 83.30 78.70 74.10 69.40 64.60 59.70 54.70 49.30
SDT 84.20 92.40 100.70 109.10 117.50 126.00 134.40 142.70
KW 2.87 3.20 3.57 3.98 4.44 4.94 5.48 6.07
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Capacity (1000 Btuh)
