PHYSICAL DATA

UNIT SIZE SERIES 018---A 024---A 030---A 036---A 042--- A 048--- A 060--- A

Operatin g Weight l b (kg) 169 (76.7) 200 (90.8) 196 (88.9) 215 (97.5)

245

(111.1)

260

(117.9)

294 (113.4)

Shipping Weight lb (kg) 207 (93.9)

233

(105.7)

242

(109.8)

257

(116.6)

290

(131.5)

303

(137.4)

345 (156.5)

Compressor Type Scroll

REFRIGERANT Puronr (R---410A)

Control TXV (Puron Hard Shutoff)

Charge lb (kg) 5.6 (2.54) 7.60 (3.45) 7.00 (3.18) 7.40 (3.34) 8.90 (4.04) 9.60 (4 .35) 12.50 (5.67)

Outdoor Heating Piston # 42 46 52 61 61 67 76

COND FAN Propeller Type, Direct Drive

Air Discharge Vertical

Air Qty (CFM) 2233 3223 3223 3810 3810 4046 4046

Motor HP 1/12 1/12 1/12 1/5 1/5 1/4 1/4

Motor RPM 800 800 800 800 800 800 800

COND COIL

Face Area (Sq ft) 15.09 20.12 20.12 22.63 17.60 17.60 25.15

Fins per In. 20 20 20 20 20 20 20

Rows 1 1 1 1 2 2 2

Circu its 4 5 5 6 7 7 9

VALVECONNECT.(In.ID)

Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8

Liquid 3/8”

REFRIGERANT TUBES ( In. OD)

Rated Vapor* 5/8 5/8 3/4 3/4 7/8 7/8 11/8

Liquid 3/8

*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling C apacity Loss table when using other sizes and lengths of lineset.

Note: See unit Installation Instruction for proper installation.

VAPOR LINE SIZING AND COOLING CAPACITY LOSS

Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line

diameters shown in the chart below are acceptable for HP systems with Puron refrigerant:

Vapor Line Sizing and Cooling Capacity Losses -- Puronr Refrigerant 1-- Stage Heat Pump Applications

Unit

Nominal

Size (Btuh)

Maximum

Liquid Line

Diameters

(In. OD)

Vapor Line

Diameters

(In.) OD

Cooling Capacity Loss (%)

Total Equivalent Line Length ft. (m)

Standard

Application

Long Line Application Requires Accessories

26--- 50

(7.9--- 15.2)

51--- 80

(15.5--- 24.4)

81--- 100

(24.7--- 30.5)

101--- 125

(30.8--- 38.1)

126--- 150

(38.4--- 45.7)

151--- 175

(46.0--- 50.3)

176--- 200

(53.6--- 60.0)

201--- 225

(61.3--- 68.6)

226--- 250

(68.9--- 76.2)

18,000

1 --- S t a g e

HP with

Puron

3/8

1/2 1 2 3 4 6 7 8 9 10

5/8 0 0 1 1 1 2 2 3 3

24,000

1 --- S t a g e

HP with

Puron

3/8

5/8 0 1 1 2 3 3 4 4 5

3/4 0 0 0 0 1 1 1 1 1

30,000

1 --- S t a g e

HP with

Puron

3/8

5/8 1 2 3 3 4 5 6 7 8

3/4 0 0 1 1 1 2 2 2 3

7/8 0 0 0 0 1 1 1 1 1

36,000

1 --- S t a g e

HP with

Puron

3/8

5/8 1 2 4 5 6 7 9 10 11

3/4 0 0 1 1 2 2 3 3 4

7/8 0 0 0 0 1 1 1 1 2

42,000

1 --- S t a g e

HP with

Puron

3/8

3/4 0 1 2 2 3 4 4 5 6

7/8 0 0 1 1 1 2 2 2 3

48,000

1 --- S t a g e

HP with

Puron

3/8

3/4 0 1 2 3 4 5 5 6 7

7/8 0 0 1 1 2 2 2 3 3

60,000

1 --- S t a g e

HP with

Puron

3/8

3/4 1 2 4 5 6 7 9 10 11

7/8 0 1 2 2 3 4 4 5 5

1 --- 1 / 8 0 0 0 1 1 1 1 1 1

Standard Length = 80 ft. (24.4 m) or less total equivalent length

Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines

Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Applica-

tion Guidelines

215B
