Bryant PREFERRED 265A User Manual

10
COMBINATION RATINGS
Unit Size
--- S e r i e s
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace Model
Factory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
E
COP
H
Capacity
H
COP
018---B
*FX4CNF018 17,800 TDR&TXV 15.00 12.00 18,000 3.62 10,400 2.34 8.2
FE4ANF002 18,000 TDR&TXV 15.50 12.50 17,800 3.68 10,300 2.38 8.3
FF1ENP018 17,400 TDR&TXV 13.20 10.90 18,000 3.40 10,800 2.22 7.9
FF1ENP024 17,700 TDR&TXV 13.50 11.10 18,000 3.46 10,900 2.24 8.0
FV4BNF002 18,000 TDR&TXV 15.50 12.50 17,800 3.68 10,300 2.38 8.3
FX4CNF024 18,000 TDR&TXV 15.00 12.40 18,000 3.66 10,400 2.38 8.3
FY4ANF018 17,400 TDR&TXV 13.00 10.80 18,000 3.40 10,800 2.20 8.0
FY4ANF024 17,600 TDR&TXV 13.20 10.90 18,000 3.40 10,900 2.22 8.0
CAP**1814A** 17,300 TDR&TXV 14.50 12.00 17,400 3.38 10,100 2.26 7.8 315(A,J)AV036070
CAP**1814A** 17,400 TXV 13.00 10.80 18,000 3.36 10,800 2.20 7.8
CAP**2414A** 17,600 TDR&TXV 15.00 12.00 17,600 3.52 10,200 2.32 8.0 315(A,J)AV036070
CAP**2414A** 17,800 TXV 13.50 11.00 18,000 3.50 10,900 2.26 8.0
CAP**2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.56 10,200 2.34 8.1 315(A,J)AV048090
CAP**2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.54 10,200 2.34 8.1 355AAV042060
CAP**2417A** 17,800 TXV 13.50 11.00 18,000 3.50 10,900 2.26 8.0
CNPF*2418A** 17,700 TXV 13.50 10.80 18,000 3.54 10,900 2.28 8.1
CNPH*2417A** 17,600 TDR&TXV 15.00 12.00 17,600 3.56 10,300 2.34 8.1 315(A,J)AV036070
CNPH*2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.60 10,300 2.34 8.2 315(A,J)AV048090
CNPH*2417A** 17,600 TDR&TXV 14.50 12.00 17,600 3.58 10,300 2.34 8.2 355AAV042040
CNPH*2417A** 17,600 TDR&TXV 15.00 12.00 17,600 3.58 10,300 2.34 8.2 355AAV042060
CNPH*2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.60 10,300 2.34 8.2 355AAV042080
CNPH*2417A** 17,700 TXV 13.50 10.80 18,000 3.54 10,900 2.28 8.1
CNPV*1814A** 17,300 TDR&TXV 15.00 12.00 17,400 3.50 10,200 2.30 8.0 315(A,J)AV036070
CNPV*1814A** 17,400 TXV 13.00 10.80 18,000 3.50 10,900 2.26 8.0
CNPV*2414A** 17,600 TDR&TXV 15.00 12.00 17,600 3.56 10,300 2.34 8.1 315(A,J)AV036070
CNPV*2414A** 17,700 TXV 13.50 10.80 18,000 3.54 10,900 2.28 8.1
CNPV*2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.60 10,300 2.34 8.2 315(A,J)AV048090
CNPV*2417A** 17,700 TDR&TXV 15.00 12.00 17,600 3.58 10,300 2.34 8.2 355AAV042060
CNPV*2417A** 17,700 TXV 13.50 10.80 18,000 3.54 10,900 2.28 8.1
CSPH*2412A** 17,600 TDR&TXV 15.00 12.00 17,600 3.54 10,300 2.34 8.1 315(A,J)AV036070
CSPH*2412A** 17,700 TDR&TXV 15.00 12.00 17,600 3.58 10,300 2.34 8.2 315(A,J)AV048090
CSPH*2412A** 17,600 TDR&TXV 14.50 12.00 17,600 3.56 10,300 2.34 8.2 355AAV042040
CSPH*2412A** 17,600 TDR&TXV 15.00 12.00 17,600 3.56 10,300 2.34 8.1 355AAV042060
CSPH*2412A** 17,700 TDR&TXV 15.00 12.00 17,600 3.58 10,300 2.34 8.2 355AAV042080
CSPH*2412A** 17,700 TXV 13.50 10.80 18,000 3.54 11,000 2.28 8.1
024---B
*FX4CNF030 23,600 TDR&TXV 15.50 12.50 23,800 3.78 14,000 2.52 8.5
FE4ANF002 23,400 TDR&TXV 15.50 12.50 23,400 3.72 13,800 2.50 8.5
FE4ANF003 23,400 TDR&TXV 16.00 13.00 23,400 3.72 13,700 2.52 8.5
FE5ANB004 24,000 TDR&TXV 16.00 13.50 23,800 3.98 13,800 2.62 9.0
FF1ENP024 23,000 TDR&TXV 13.50 11.20 24,000 3.48 14,600 2.34 8.1
FF1ENP030 23,000 TDR&TXV 13.50 11.20 24,000 3.50 14,500 2.34 8.1
FV4BNF002 23,400 TDR&TXV 15.50 12.50 23,400 3.72 13,800 2.50 8.5
FV4BNF003 23,400 TDR&TXV 16.00 13.00 23,400 3.72 13,700 2.52 8.5
FX4CNF024 23,200 TDR&TXV 15.00 12.40 23,600 3.66 14,000 2.46 8.4
FY4ANF024 22,800 TDR&TXV 13.50 11.40 24,000 3.48 14,400 2.34 8.0
FY4ANF030 23,000 TDR&TXV 14.00 11.50 24,000 3.58 14,500 2.38 8.2
CAP**2414A** 22,800 TDR&TXV 15.00 12.50 23,200 3.56 13,700 2.44 8.2 315(A,J)AV036070
CAP**2414A** 23,000 TXV 14.00 11.20 24,000 3.54 14,600 2.36 8.2
CAP**2417A** 23,000 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 315(A,J)AV048090
CAP**2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.58 13,700 2.44 8.2 355AAV042060
CAP**2417A** 23,000 TXV 14.00 11.20 24,000 3.54 14,600 2.36 8.2
CAP**3014A** 23,200 TDR&TXV 15.50 12.50 23,200 3.58 13,700 2.46 8.2 315(A,J)AV036070
CAP**3014A** 23,200 TXV 14.00 11.50 24,000 3.56 14,600 2.38 8.2
CAP**3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV048090
CAP**3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,700 2.46 8.3 355AAV042060
CAP**3017A** 23,200 TXV 14.00 11.50 24,000 3.56 14,600 2.38 8.2
CNPF*2418A** 23,000 TXV 13.50 11.20 24,000 3.60 14,600 2.38 8.3
CNPH*2417A** 22,800 TDR&TXV 15.00 12.50 23,200 3.60 13,800 2.44 8.3 315(A,J)AV036070
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 315(A,J)AV048090
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 315(A,J)AV060110
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 315(A,J)AV066135
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 315(A,J)AV066155
See notes on pg. 17
265A

Bryant PREFERRED 265A Specifications

Fan Specifications

condenser fan type	direct-drive propeller
condenser fan motor phase	1-phase
condenser fan motor insulation class	class B

Power

nominal unit electrical characteristics	__ v, single phase, 60 hz
control circuit voltage	24v
voltage limits	_ v to ___ v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor oil type	POE compressor oil
refrigeration circuit components	liquid-line shutoff valve, vapor-line shutoff valve, system charge, accumulator, reversing valve
