Bryant PREFERRED 265A User Manual

11
COMBINATION RATINGS CONTINUED
Unit Size
--- S e r i e s
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace Model
Factory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
E
COP
H
Capacity
H
COP
024---B
CNPH*2417A** 23,000 TDR&TXV 15.00 12.00 23,200 3.64 13,800 2.46 8.3 355AAV042040
CNPH*2417A** 22,800 TDR&TXV 15.00 12.50 23,200 3.62 13,800 2.46 8.3 355AAV042060
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 355AAV042080
CNPH*2417A** 22,800 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 355AAV060080
CNPH*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.66 13,800 2.46 8.3 355AAV060100
CNPH*2417A** 22,800 TDR&TXV 15.00 12.00 23,200 3.60 13,800 2.44 8.3 355AAV060120
CNPH*2417A** 23,000 TXV 14.00 11.50 24,000 3.60 14,600 2.38 8.3
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 315(A,J)AV036070
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV048090
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV060110
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV066135
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.4 315(A,J)AV066155
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.48 8.3 355AAV042040
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,700 2.48 8.3 355AAV042060
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.48 8.3 355AAV042080
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,700 2.48 8.3 355AAV060080
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,800 2.48 8.4 355AAV060100
CNPH*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 355AAV060120
CNPH*3017A** 23,200 TXV 14.00 11.50 24,000 3.58 14,600 2.38 8.2
CNPV*2414A** 22,800 TDR&TXV 15.00 12.50 23,200 3.60 13,800 2.44 8.3 315(A,J)AV036070
CNPV*2414A** 23,000 TXV 14.00 11.50 24,000 3.60 14,600 2.38 8.3
CNPV*2417A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 315(A,J)AV048090
CNPV*2417A** 22,800 TDR&TXV 15.00 12.50 23,200 3.62 13,800 2.46 8.3 355AAV042060
CNPV*2417A** 23,000 TXV 14.00 11.20 24,000 3.60 14,600 2.38 8.3
CNPV*3014A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 315(A,J)AV036070
CNPV*3014A** 23,200 TXV 14.00 11.50 24,000 3.58 14,600 2.38 8.2
CNPV*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV048090
CNPV*3017A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,700 2.48 8.3 355AAV042060
CNPV*3017A** 23,200 TXV 14.00 11.50 24,000 3.58 14,600 2.38 8.2
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.62 13,800 2.46 8.3 315(A,J)AV036070
CSPH*2412A** 23,000 TDR&TXV 15.50 12.50 23,200 3.66 13,800 2.48 8.4 315(A,J)AV048090
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,900 2.46 8.3 315(A,J)AV060110
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.4 315(A,J)AV066135
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.66 13,800 2.46 8.4 315(A,J)AV066155
CSPH*2412A** 23,000 TDR&TXV 15.00 12.00 23,200 3.64 13,900 2.46 8.3 355AAV042040
CSPH*2412A** 23,000 TDR&TXV 15.50 12.50 23,200 3.64 13,800 2.46 8.3 355AAV042060
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,900 2.46 8.3 355AAV042080
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.64 13,800 2.46 8.3 355AAV060080
CSPH*2412A** 23,000 TDR&TXV 15.50 12.50 23,200 3.66 13,900 2.46 8.4 355AAV060100
CSPH*2412A** 23,000 TDR&TXV 15.00 12.50 23,200 3.60 13,800 2.44 8.3 355AAV060120
CSPH*2412A** 23,000 TXV 14.00 11.50 24,000 3.64 14,600 2.40 8.3
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 315(A,J)AV036070
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,700 2.48 8.3 315(A,J)AV048090
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.46 8.3 315(A,J)AV060110
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,800 2.48 8.3 315(A,J)AV066135
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,800 2.48 8.3 315(A,J)AV066155
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.46 8.3 355AAV042040
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,700 2.46 8.3 355AAV042060
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.46 8.3 355AAV042080
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.62 13,800 2.46 8.3 355AAV060080
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.64 13,800 2.48 8.3 355AAV060100
CSPH*3012A** 23,200 TDR&TXV 15.50 12.50 23,200 3.60 13,800 2.46 8.3 355AAV060120
CSPH*3012A** 23,200 TXV 14.00 11.50 24,000 3.58 14,600 2.38 8.3
030--B
*FX4CNF030 29,200 TDR&TXV 15.50 12.50 29,400 3.80 17,200 2.50 8.5
FE4ANF002 29,000 TDR&TXV 15.50 13.00 29,000 3.78 16,900 2.50 8.5
FE4ANF003 29,000 TDR&TXV 16.00 13.20 28,800 3.80 16,700 2.52 8.5
FE4ANF005 30,000 TDR&TXV 16.00 13.50 29,200 3.98 16,900 2.60 9.0
FE5ANB004 30,000 TDR&TXV 16.00 13.50 29,200 4.10 16,900 2.64 9.0
FF1ENP030 28,600 TDR&TXV 14.00 11.50 29,800 3.60 17,600 2.38 8.1
FF1ENP036 29,000 TDR&TXV 14.00 11.50 30,000 3.66 17,700 2.42 8.3
FV4BNF002 29,000 TDR&TXV 15.50 13.00 29,000 3.78 16,900 2.50 8.5
FV4BNF003 29,200 TDR&TXV 16.00 13.00 28,800 3.80 16,700 2.52 8.5
FV4BNF005 30,000 TDR&TXV 16.00 13.50 29,200 3.98 16,900 2.60 9.0
FX4CN(B,F)036 29,400 TDR&TXV 15.50 12.50 29,600 3.84 17,300 2.52 8.6
FY4ANF030 28,800 TDR&TXV 14.00 11.50 30,000 3.68 17,700 2.40 8.4
FY4ANF036 28,800 TDR&TXV 13.50 11.50 30,000 3.64 17,800 2.40 8.2
CAP**3014A** 28,800 TDR&TXV 15.50 12.50 28,800 3.66 16,900 2.46 8.2 315(A,J)AV036070
CAP**3014A** 29,000 TXV 14.00 11.50 30,000 3.64 17,700 2.40 8.2
See notes on pg. 17
265A

Bryant PREFERRED 265A Specifications

Fan Specifications

condenser fan type	direct-drive propeller
condenser fan motor phase	1-phase
condenser fan motor insulation class	class B

Power

nominal unit electrical characteristics	__ v, single phase, 60 hz
control circuit voltage	24v
voltage limits	_ v to ___ v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor oil type	POE compressor oil
refrigeration circuit components	liquid-line shutoff valve, vapor-line shutoff valve, system charge, accumulator, reversing valve
