Bryant PREFERRED 265A - Page 19

19
DETAILED COOLING CAPACITIES CONTINUED
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
265ANA024---B Outdoor Section With FX4CNF030 Indoor Section
700
72 28.21 14.49 1.47 26.92 13.99 1.65 25.57 13.46 1.85 24.13 12.92 2.07 22.59 12.34 2.31 20.91 11.71 2.57
67 25.60 17.78 1.46 24.41 17.26 1.64 23.15 16.72 1.84 21.81 16.16 2.06 20.38 15.56 2.30 18.81 14.91 2.56
63 23.74 17.18 1.46 22.61 16.65 1.64 21.42 16.11 1.84 20.16 15.53 2.06 18.80 14.92 2.29 17.33 14.27 2.55
62 23.27 21.07 1.46 22.17 20.52 1.64 21.02 19.95 1.84 19.80 19.32 2.05 18.55 18.55 2.29 17.37 17.37 2.55
57 22.41 22.41 1.46 21.53 21.53 1.64 20.61 20.61 1.83 19.62 19.62 2.05 18.55 18.55 2.29 17.37 17.37 2.55
800
72 28.81 15.19 1.49 27.47 14.68 1.67 26.06 14.14 1.87 24.57 13.59 2.09 22.97 13.00 2.33 21.24 12.37 2.59
67 26.16 18.90 1.49 24.91 18.37 1.67 23.60 17.82 1.87 22.21 17.25 2.09 20.72 16.63 2.32 19.11 15.97 2.58
63 24.26 18.23 1.48 23.08 17.69 1.66 21.84 17.14 1.86 20.53 16.55 2.08 19.12 15.93 2.32 17.60 15.26 2.57
62 23.82 22.56 1.48 22.69 21.98 1.66 21.53 21.32 1.86 20.39 20.39 2.08 19.26 19.26 2.32 18.02 18.02 2.58
57 23.35 23.35 1.48 22.42 22.42 1.66 21.44 21.44 1.86 20.39 20.39 2.08 19.26 19.26 2.32 18.02 18.02 2.58
900
72 29.28 15.85 1.51 27.90 15.33 1.70 26.44 14.79 1.90 24.91 14.22 2.12 23.26 13.63 2.36 21.48 12.99 2.62
67 26.58 19.97 1.51 25.29 19.43 1.69 23.94 18.87 1.89 22.51 18.28 2.11 20.98 17.66 2.35 19.34 16.98 2.60
63 24.66 19.22 1.50 23.44 18.68 1.68 22.17 18.11 1.88 20.82 17.52 2.10 19.37 16.88 2.34 17.82 16.18 2.59
62 24.30 23.89 1.50 23.18 23.18 1.68 22.14 22.14 1.88 21.05 21.05 2.10 19.86 19.86 2.34 18.56 18.56 2.60
57 24.15 24.15 1.50 23.18 23.18 1.68 22.15 22.15 1.88 21.05 21.05 2.10 19.86 19.86 2.34 18.57 18.57 2.60
Cooling Indoor Model Capacity Power Furnace Model
*FX4CNF030 1.00 1.00
FE4ANF002 0.99 0.99
FE4ANF003 0.99 0.95
FE5ANB004 1.02 0.94
FF1ENP024 0.97 1.09
FF1ENP030 0.97 1.09
FV4BNF002 0.99 0.99
FV4BNF003 0.99 0.95
FX4CNF024 0.98 0.99
FY4ANF024 0.97 1.06
FY4ANF030 0.97 1.06
CAP**2414A** 0.97 1.09
CAP**2417A** 0.97 1.09
CAP**3014A** 0.98 1.07
CAP**3017A** 0.98 1.07
CNPF*2418A** 0.97 1.09
CNPH*2417A** 0.97 1.06
CNPH*3017A** 0.98 1.07
CNPV*2414A** 0.97 1.06
CNPV*2417A** 0.97 1.09
CNPV*3014A** 0.98 1.07
CNPV*3017A** 0.98 1.07
CSPH*2412A** 0.97 1.06
CSPH*3012A** 0.98 1.07
CAP**2414A** 0.97 0.97 315(A,J)AV036070
CAP**3014A** 0.98 0.98 315(A,J)AV036070
CNPH*2417A** 0.97 0.97 315(A,J)AV036070
CNPH*3017A** 0.98 0.98 315(A,J)AV036070
CNPV*2414A** 0.97 0.97 315(A,J)AV036070
CNPV*3014A** 0.98 0.98 315(A,J)AV036070
CSPH*2412A** 0.97 0.97 315(A ,J)AV036070
CSPH*3012A** 0.98 0.98 315(A ,J)AV036070
CAP**2417A** 0.97 0.97 315(A,J)AV048090
CAP**3017A** 0.98 0.98 315(A,J)AV048090
CNPH*2417A** 0.97 0.97 315(A,J)AV048090
CNPH*3017A** 0.98 0.98 315(A,J)AV048090
CNPV*2417A** 0.97 0.97 315(A,J)AV048090
CNPV*3017A** 0.98 0.98 315(A,J)AV048090
CSPH*2412A** 0.97 0.97 315(A ,J)AV048090
CSPH*3012A** 0.98 0.98 315(A ,J)AV048090
CNPH*2417A** 0.97 0.97 315(A,J)AV060110
CNPH*3017A** 0.98 0.98 315(A,J)AV060110
CSPH*2412A** 0.97 0.97 315(A ,J)AV060110
CSPH*3012A** 0.98 0.98 315(A ,J)AV060110
CNPH*2417A** 0.97 0.97 315(A,J)AV066135
CNPH*3017A** 0.98 0.98 315(A,J)AV066135
CSPH*2412A** 0.97 0.97 315(A ,J)AV066135
CSPH*3012A** 0.98 0.98 315(A ,J)AV066135
CNPH*2417A** 0.97 0.97 315(A,J)AV066155
CNPH*3017A** 0.98 0.98 315(A,J)AV066155
CSPH*2412A** 0.97 0.97 315(A ,J)AV066155
CSPH*3012A** 0.98 0.98 315(A ,J)AV066155
Cooling Indoor Model Capacity Power Furnace Model
CNPH*2417A** 0.97 1.02 355AAV042040
CNPH*3017A** 0.98 0.98 355AAV042040
CSPH*2412A** 0.97 1.02 355AAV042040
CSPH*3012A** 0.98 0.98 355AAV042040
CAP**2417A** 0.97 0.97 355AAV042060
CAP**3017A** 0.98 0.98 355AAV042060
CNPH*2417A** 0.97 0.97 355AAV042060
CNPH*3017A** 0.98 0.98 355AAV042060
CNPV*2417A** 0.97 0.97 355AAV042060
CNPV*3017A** 0.98 0.98 355AAV042060
CSPH*2412A** 0.97 0.97 355AAV042060
CSPH*3012A** 0.98 0.98 355AAV042060
CNPH*2417A** 0.97 0.97 355AAV042080
CNPH*3017A** 0.98 0.98 355AAV042080
CSPH*2412A** 0.97 0.97 355AAV042080
CSPH*3012A** 0.98 0.98 355AAV042080
CNPH*2417A** 0.97 0.97 355AAV060080
CNPH*3017A** 0.98 0.98 355AAV060080
CSPH*2412A** 0.97 0.97 355AAV060080
CSPH*3012A** 0.98 0.98 355AAV060080
CNPH*2417A** 0.97 0.97 355AAV060100
CNPH*3017A** 0.98 0.98 355AAV060100
CSPH*2412A** 0.97 0.97 355AAV060100
CSPH*3012A** 0.98 0.98 355AAV060100
CNPH*2417A** 0.97 1.01 355AAV060120
CNPH*3017A** 0.98 0.98 355AAV060120
CSPH*2412A** 0.97 0.97 355AAV060120
CSPH*3012A** 0.98 0.98 355AAV060120
See notes on pg. 24
