Bryant PREFERRED 265A - Page 23

23
DETAILED COOLING CAPACITIES CONTINUED
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Capacity
MBtuh†
Tot a l
Sys-
tem
KW*
*
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
Tot a l
Sens
‡
265ANA048---B Outdoor Section With FX4CNF060 Indoor Section
1400
72 57.47 29.60 2.93 54.70 28.51 3.33 51.81 27.40 3.76 48.81 26.26 4.22 45.64 25.08 4.71 43.64 24.34 4.69
67 52.33 36.48 2.94 49.77 35.37 3.34 47.13 34.24 3.76 44.38 33.08 4.21 41.48 31.87 4.70 38.36 30.59 5.21
63 48.56 35.25 2.95 46.18 34.15 3.34 43.71 33.02 3.75 41.15 31.86 4.20 38.46 30.66 4.68 35.56 29.38 5.19
62 47.58 43.31 2.95 45.25 42.17 3.34 42.86 40.98 3.75 40.41 39.73 4.20 38.01 38.01 4.68 35.68 35.68 5.19
57 45.92 45.92 2.95 44.08 44.08 3.34 42.16 42.16 3.75 40.15 40.15 4.20 38.01 38.01 4.68 35.68 35.68 5.19
1600
72 58.63 31.04 2.97 55.74 29.94 3.37 52.73 28.81 3.80 49.61 27.65 4.26 46.32 26.45 4.76 44.28 25.72 4.74
67 53.44 38.83 2.98 50.76 37.70 3.38 48.00 36.55 3.80 45.14 35.36 4.26 42.13 34.13 4.74 38.89 32.81 5.26
63 49.64 37.48 2.99 47.14 36.35 3.38 44.56 35.19 3.80 41.89 34.01 4.25 39.09 32.77 4.73 36.09 31.46 5.24
62 48.71 46.49 2.99 46.31 45.26 3.38 43.89 43.89 3.80 41.73 41.73 4.25 39.45 39.45 4.73 36.95 36.95 5.25
57 47.89 47.89 2.99 45.92 45.92 3.38 43.88 43.88 3.80 41.73 41.73 4.25 39.45 39.45 4.73 36.96 36.96 5.25
1800
72 59.52 32.41 3.01 56.53 31.30 3.41 53.42 30.16 3.85 50.20 28.99 4.31 46.81 27.76 4.80 44.76 27.04 4.79
67 54.29 41.09 3.03 51.51 39.94 3.42 48.66 38.76 3.85 45.71 37.55 4.30 42.61 36.29 4.79 39.29 34.93 5.31
63 50.46 39.60 3.03 47.87 38.45 3.42 45.21 37.27 3.84 42.45 36.05 4.29 39.57 34.79 4.78 36.50 33.43 5.29
62 49.71 49.33 3.03 47.48 47.48 3.42 45.31 45.31 3.84 43.04 43.04 4.30 40.63 40.63 4.78 37.99 37.99 5.30
57 49.56 49.56 3.03 47.48 47.48 3.42 45.31 45.31 3.84 43.04 43.04 4.30 40.63 40.63 4.78 38.00 38.00 5.30
Cooling Indoor Model Capacity Power Furnace Model
*FX4CN(B,F)060 1.00 1.00
FE4ANB006 1.00 1.00
FE4ANF005 1.00 1.04
FV4BNB006 1.00 1.00
FV4BNF005 1.00 1.04
FX4CN(B,F)048 1.00 1.04
FY4ANB060 1.00 1.08
FY4ANF048 1.00 1.16
CAP**4817A** 0.98 1.06
CAP**4821A** 1.00 1.08
CAP**4824A** 1.00 1.08
CAP**6021A** 1.00 1.08
CAP**6024A** 1.00 1.08
CNPF*4818A** 0.98 1.11
CNPH*4821A** 1.00 1.08
CNPH*6024A** 1.00 1.08
CNPV*4821A** 1.00 1.08
CNPV*4824A** 1.00 1.08
CNPV*6024A** 1.00 1.08
CSPH*4812A** 1.00 1.13
CSPH*6012A** 1.00 1.08
CAP**4817A** 0.96 1.04 315(A,J)AV048090
CNPH*4821A** 0.98 1.06 315(A,J)AV048090
CNPH*6024A** 1.00 1.08 315(A,J)AV048090
CSPH*4812A** 0.98 1.06 315(A,J)AV048090
CSPH*6012A** 1.00 1.08 315(A,J)AV048090
CAP**4821A** 0.98 1.06 315(A,J)AV060110
CAP**6021A** 1.00 1.04 315(A,J)AV060110
CNPH*4821A** 0.98 1.06 315(A,J)AV060110
CNPH*6024A** 1.00 1.04 315(A,J)AV060110
CNPV*4821A** 0.98 1.06 315(A,J)AV060110
CSPH*4812A** 0.98 1.06 315(A,J)AV060110
CSPH*6012A** 1.00 1.08 315(A,J)AV060110
CAP**4824A** 0.99 1.07 315(A,J)AV066135
CAP**6024A** 1.00 1.04 315(A,J)AV066135
CNPH*4821A** 0.99 1.07 315(A,J)AV066135
CNPH*6024A** 1.00 1.04 315(A,J)AV066135
CNPV*4824A** 0.99 1.03 315(A,J)AV066135
CNPV*6024A** 1.00 1.04 315(A,J)AV066135
CSPH*4812A** 0.99 1.07 315(A,J)AV066135
CSPH*6012A** 1.00 1.04 315(A,J)AV066135
CAP**4824A** 0.99 1.03 315(A,J)AV066155
CAP**6024A** 1.00 1.04 315(A,J)AV066155
CNPH*4821A** 0.99 1.03 315(A,J)AV066155
CNPH*6024A** 1.00 1.04 315(A,J)AV066155
CNPV*4824A** 0.99 1.03 315(A,J)AV066155
CNPV*6024A** 1.00 1.04 315(A,J)AV066155
CSPH*4812A** 0.99 1.03 315(A,J)AV066155
CSPH*6012A** 1.00 1.04 315(A,J)AV066155
Cooling Indoor Model Capacity Power Furnace Model
CAP**4821A** 0.98 1.06 355AAV060080
CAP**6021A** 1.00 1.08 355AAV060080
CNPH*4821A** 0.98 1.06 355AAV060080
CNPH*6024A** 1.00 1.08 355AAV060080
CNPV*4821A** 0.98 1.06 355AAV060080
CSPH*4812A** 0.98 1.06 355AAV060080
CSPH*6012A** 1.00 1.08 355AAV060080
CAP**4821A** 0.98 1.06 355AAV060100
CAP**6021A** 1.00 1.08 355AAV060100
CNPH*4821A** 0.99 1.07 355AAV060100
CNPH*6024A** 1.00 1.08 355AAV060100
CNPV*4821A** 0.99 1.07 355AAV060100
CSPH*4812A** 0.98 1.06 355AAV060100
CSPH*6012A** 1.00 1.08 355AAV060100
CAP**4824A** 0.98 1.06 355AAV060120
CAP**6024A** 1.00 1.08 355AAV060120
CNPH*4821A** 0.98 1.06 355AAV060120
CNPH*6024A** 1.00 1.08 355AAV060120
CNPV*4824A** 0.98 1.06 355AAV060120
CNPV*6024A** 1.00 1.08 355AAV060120
CSPH*4812A** 0.98 1.06 355AAV060120
CSPH*6012A** 1.00 1.08 355AAV060120
See notes on pg. 24
265A
