Bryant PREFERRED 265A - Page 28

28
HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
-- 3 7 17 27 37 47 57 67
EDB CFM
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
Capacity MBtuh
To t a l
System
KW†
To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ*
265ANA036-- B Outdoo r Section With FX4CNF 042 Indoor Section
65
1050 12.64 11.63 2.00 16.28 14.96 2.10 20.13 18.35 2.20 24.23 21.52 2.31 28.87 26.28 2.44 34.11 34.11 2.59 39.94 39.94 2.78 46.89 46.89 3.03 1200 12.89 11.86 2.01 16.53 15.19 2.10 20.41 18.61 2.19 24.56 21.81 2.29 29.36 26.72 2.41 34.61 34.61 2.55 40.67 40.67 2.73 47.75 47.75 2.96 1350 13.10 12.05 2.03 16.77 15.41 2.11 20.66 18.84 2.20 24.85 22.07 2.28 29.70 27.02 2.40 35.02 35.02 2.53 41.06 41.06 2.70 48.36 48.36 2.93
70
1050 12.02 11.06 2.07 15.74 14.46 2.19 19.64 17.91 2.30 23.77 21.11 2.42 28.30 25.76 2.56 33.50 33.50 2.72 39.21 39.21 2.91 45.94 45.94 3.16 1200 12.27 11.29 2.09 16.04 14.74 2.20 19.94 18.18 2.30 24.09 21.40 2.40 28.72 26.14 2.52 34.00 34.00 2.67 39.82 39.82 2.85 46.82 46.82 3.09 1350 12.49 11.50 2.11 16.27 14.95 2.21 20.19 18.41 2.30 24.36 21.64 2.39 29.07 26.45 2.51 34.40 34.40 2.65 40.33 40.33 2.82 47.44 47.44 3.05
75
1050 11.33 10.42 2.15 15.17 13.94 2.28 19.12 17.44 2.41 23.28 20.67 2.54 27.73 25.24 2.68 32.90 32.90 2.85 38.50 38.50 3.05 45.01 45.01 3.30 1200 11.60 10.67 2.16 15.44 14.19 2.29 19.42 17.71 2.40 23.61 20.97 2.52 28.15 25.62 2.64 33.38 33.38 2.80 39.11 39.11 2.98 45.88 45.88 3.22 1350 11.82 10.88 2.18 15.68 14.41 2.30 19.68 17.95 2.40 23.89 21.21 2.51 28.50 25.93 2.62 33.78 33.78 2.77 39.57 39.57 2.94 46.52 46.52 3.18
Heating Indoor Model Capacity Power Furnace Model
*FX4CN(B,F)042 1.00 1.00
FE4ANB006 0.99 0.95
FE4ANF002 0.98 1.03 FE4ANF003 0.97 1.01 FE4ANF005 0.98 0.97
FE5ANB004 0.99 0.94
FF1ENP036 1.01 1.10
FV4BNB006 0.99 0.95
FV4BNF002 0.98 1.03 FV4BNF003 0.97 1.01 FV4BNF005 0.98 0.97
FX4CN(B,F)036 0.99 1.02
FY4ANF036 1.01 1.10 FY4ANF042 1.02 1.07
CAP**3614A** 0.98 1.07 CAP**3617A** 1.01 1.08 CAP**3621A** 1.01 1.08 CAP**4221A** 1.01 1.08 CAP**4224A** 1.01 1.08
CNPF*3618A** 1.01 1.09
CNPH*3617A** 1.01 1.09 CNPH*4221A** 1.01 1.07 CNPV*3617A** 1.01 1.09 CNPV*3621A** 1.01 1.09 CNPV*4221A** 1.01 1.07 CSPH*3612A** 1.01 1.05 CSPH*4212A** 1.01 1.04
CAP**3614A** 0.98 1.06 315(A,J)AV036070
CNPH*3617A** 0.97 1.05 315(A,J)AV036070 CNPH*4221A** 0.98 1.03 315(A,J)AV036070 CSPH*3612A** 0.97 1.01 315(A,J)AV036070 CSPH*4212A** 0.98 1.01 315(A,J)AV036070
CAP**3617A** 0.97 1.03 315(A,J)AV048090
CNPH*3617A** 0.97 1.04 315(A,J)AV048090 CNPH*4221A** 0.97 1.01 315(A,J)AV048090 CNPV*3617A** 0.97 1.04 315(A,J)AV048090 CSPH*3612A** 0.97 1.00 315(A,J)AV048090 CSPH*4212A** 0.98 0.99 315(A,J)AV048090
CAP**3621A** 0.97 1.03 315(A,J)AV060110 CAP**4221A** 0.97 1.01 315(A,J)AV060110
CNPH*3617A** 0.97 1.04 315(A,J)AV060110
Heating Indoor Model Capacity Power Furnace Model
CNPH*4221A** 0.97 1.00 315(A,J)AV060110 CNPV*3621A** 0.97 1.04 315(A,J)AV060110 CNPV*4221A** 0.97 1.00 315(A,J)AV060110 CSPH*3612A** 0.97 1.00 315(A,J)AV060110 CSPH*4212A** 0.98 0.99 315(A,J)AV060110
CAP**4224A** 0.97 1.01 315(A,J)AV066135
CNPH*3617A** 0.97 1.04 315(A,J)AV066135 CNPH*4221A** 0.96 0.99 315(A,J)AV066135 CSPH*3612A** 0.97 1.00 315(A,J)AV066135 CSPH*4212A** 0.98 0.99 315(A,J)AV066135
CAP**4224A** 0.97 1.00 315(A,J)AV066155
CNPH*3617A** 0.97 1.03 315(A,J)AV066155 CNPH*4221A** 0.96 0.99 315(A,J)AV066155 CSPH*3612A** 0.97 0.99 315(A,J)AV066155 CSPH*4212A** 0.98 0.98 315(A,J)AV066155
CAP**4224A** 0.98 1.04 355AAV042040
CNPH*3617A** 0.97 1.06 355AAV042040 CNPH*4221A** 0.97 1.02 355AAV042040 CSPH*3612A** 0.97 1.01 355AAV042040 CSPH*4212A** 0.97 1.00 355AAV042040
CAP**3617A** 0.97 1.04 355AAV042060
CNPH*3617A** 0.97 1.05 355AAV042060 CNPH*4221A** 0.97 1.01 355AAV042060 CNPV*3617A** 0.97 1.05 355AAV042060 CSPH*3612A** 0.97 1.01 355AAV042060 CSPH*4212A** 0.98 1.00 355AAV042060
CAP**3621A** 0.97 1.05 355AAV042080 CAP**4221A** 0.98 1.04 355AAV042080
CNPH*3617A** 0.97 1.06 355AAV042080 CNPH*4221A** 0.97 1.02 355AAV042080 CNPV*3621A** 0.97 1.06 355AAV042080 CNPV*4221A** 0.97 1.02 355AAV042080 CSPH*3612A** 0.97 1.02 355AAV042080 CSPH*4212A** 0.98 1.01 355AAV042080
CAP**3621A** 0.97 1.04 355AAV060080 CAP**4221A** 0.98 1.03 355AAV060080
CNPH*3617A** 0.97 1.05 355AAV060080 CNPH*4221A** 0.97 1.02 355AAV060080 CNPV*3621A** 0.97 1.05 355AAV060080 CNPV*4221A** 0.97 1.02 355AAV060080 CSPH*3612A** 0.97 1.01 355AAV060080
Heating Indoor Model Capacity Power Furnace Model
CSPH*4212A** 0.98 1.00 355AAV060080
CAP**3621A** 0.97 1.03 355AAV060100 CAP**4221A** 0.98 1.03 355AAV060100
CNPH*3617A** 0.97 1.05 355AAV060100 CNPH*4221A** 0.97 1.01 355AAV060100 CNPV*3621A** 0.97 1.04 355AAV060100 CNPV*4221A** 0.97 1.01 355AAV060100 CSPH*3612A** 0.97 1.00 355AAV060100 CSPH*4212A** 0.98 1.00 355AAV060100
CAP**4224A** 0.97 1.02 355AAV060120
CNPH*3617A** 0.97 1.05 355AAV060120 CNPH*4221A** 0.97 1.01 355AAV060120 CSPH*3612A** 0.97 1.01 355AAV060120 CSPH*4212A** 0.98 1.00 355AAV060120
See notes on pg. 31
265A
