Fig. 49—TXV in Cooling Mode
A88406
OUTLET
INLET
PUSHRODS
BYPASS TXV
DIAPHRAGM
NEEDLE
VALVE
SPRING
CHECK VALVE
(CLOSED)
BYPASS TUBE
DISTRIBUTOR
FEEDER TUBES
CAPILLARY TUBE
COIL
BULB
EXTERNAL EQUALIZER TUBE
Fig. 50—TXV in Heating Mode
A88405
OUTLET
INLET
PUSHRODS
BYPASS TXV
DIAPHRAGM
NEEDLE
VALVE
SPRING
CHECK VALVE
(OPEN)
BYPASS TUBE
DISTRIBUTOR
FEEDER TUBES
CAPILLARY TUBE
COIL
BULB
EXTERNAL EQUALIZER TUBE
—42—
