Page 16
Advanced Setup
This is normally done by the installer at initial installation.
Use these buttons to
adjust the deadband
from 1 to 6 degrees.
Use these buttons to
adjust the cycles/hour
from 2 to 6.
d=no limit (zoning)
d1=d+no compressor
lockout.
Enter advanced setup by adjusting the program switch to
SET. When the clock is flashing, press NEXT for 5 seconds.
Do not release the button until this screen appears.
Select YES to have the
backlight always on, or NO
to turn off the backlight 8
seconds after a button press.
Use these buttons to select
thermostat operation in
degrees C or F.
If degrees C is selected two presses of the Up or Down
buttons will be required to change the setpoint.
Adjust the program switch to OFF or RUN to exit
Advanced Setup.
F
L I
Yes
NEXT
NEXT
NEXT
Step only
appears
if connect-
ed to 24
volt power
I
6
To Next Page
