Bryant ZONE PERFECT TWO-ZONE User Manual

TIMEGUARD
The Zone Perfect Two-Zone provides equipment protection with
an internal 5-minute timeguard delay. This delay is present upon
initial power up. There is also a 5-minute timeguard delay for all
cooling (Y1) and heat pump modes. The time guard can be cleared
by using the comprotec override feature. Second-stage (Y2) and
(W2) will have a 5-minute delay between stages and also can be
cleared using the comprotec override feature.
→ Fig. 13—Electronic Non-Programmable Thermostat Wiring Diagrams
A97294
W
/W1
C
Y
/Y2
R24 VAC HOT
TWO-ZONE BOARD
THERMOSTAT
INPUT
24 VAC COMM
HEAT STAGE 1
COOL STAGE 2
FAN
HEAT STAGE 2
COOL STAGE 1
N/A
TROUBLE
OUTDOOR
SENSOR
CONNECTION
TWO-STAGE HEAT,
TWO-STAGE COOL

SEE NOTES 1, 2, AND 3
G
O
/W2
Y1
C
R
W1
Y2
G
W2
Y1
B
L
S1
S2
W
/W1
C
Y
/Y2
R24 VAC HOT
NON-PROGRAMMABLE
ELECTRONIC
THERMOSTAT
MODEL AC
NON-PROGRAMMABLE
ELECTRONIC
THERMOSTAT
MODEL HP
TWO-ZONE BOARD
THERMOSTAT
INPUT
24 VAC COMM
HEAT STAGE 1
COOL STAGE 1
FAN
SINGLE-STAGE HEAT,
SINGLE-STAGE COOL

SEE NOTES 1 AND 3
G
C
R
W1
Y1
G
W2
Y2
NON-PROGRAMMABLE
ELECTRONIC
THERMOSTAT
MODEL 2S
*
*
W
/W1
C
Y
/Y2
R24 VAC HOT
TWO-ZONE BOARD
THERMOSTAT
INPUT
24 VAC COMM
HEAT STAGE 1
COOL STAGE 1
FAN
HEAT STAGE 2
N/A
N/A
N/A
OUTDOOR
SENSOR
CONNECTION
TWO-STAGE HEAT,
SINGLE-STAGE COOL

SEE NOTES 1, 2, AND 3
G
O
/W2
Y1
C
R
W1
Y1
G
Y2
W2
B
L
S1
S2
*
WIRING DIAGRAM NOTES:
* Hook up G on zone 1 thermostat only.
Cut R19 jumper on thermostat.
Disable timeguard and cycle protection in thermostat by setting
it to ZONE mode. Refer to thermostat Installation Instructions for
details on how to do this.
1.
2.
3.
—7—
