Brymen BM786 - Continuity, Diode, and Capacitance Specifications

26
Ohms
RANGE
Accuracy
1)
600.00

0.085%+10d
6.0000k

, 60.000k

0.085%+4d
600.00k

0.15%+4d
6.0000M

2)
1.5%+5d
60.000M

3) 4)
2.0%+5d
99.99nS
5)
1.0%+10d
Open Circuit Voltage: < 1.3VDC (< 1.5VDC for 600

range)
1)
Temperature Coefficient: 0.20 x (specified accuracy)/

C @ (-20

C ~ 18

C or 28

C ~
55

C)
2)
Constant Test Current: 0.1
µ
A Typical
3)
Constant Test Current: 0.01
µ
A Typical
4)
Specified accuracy adds 0.5% @ >50M

5)
Specified accuracy adds 30d @ <10nS
BeepLit
TM
Continuity Tester
Audible threshold: between 100

and 420

Response time < 100

s
Audible Indication: Beep Sound
Visible Response: LCD Backlight
BeepLit
TM
Diode Tester
RANGE
Accuracy
Test Current (Typical)
Open Circuit Voltage
3.0000V
1%+20d
0.35mA
< 3.1 VDC
Short-Beep-Alert Threshold: Drop Across 0.850V
BeepLit™ continuous ON Threshold: < 0.100V
Audible Indication: Beep Sound
Visible Indication: LCD Backlight
Capacitance
RANGE
Accuracy
1) 2)
10.00nF
1.0% + 10d
100.0nF~1000nF
1.0% + 2d
10.00

F~1.000mF
1.8% + 4d
10.00mF
2.0% + 4d
1)
Accuracies with film capacitor or better
2)
Temperature Coefficient: 0.20 x (specified accuracy)/

C @ (-20

C ~ 18

C or 28

C ~
