Brymen BM786 - EF-Detection and Recording Mode Specifications

29
Function RANGE
Sensitivity (Sine RMS)
Range
6V
0.4V
10Hz ~ 50kHz
60V
4V
10Hz ~ 50kHz
600V
40V
10Hz ~ 30kHz
1000V
400V
10Hz ~ 5kHz
VFD 600V
40V
10Hz ~ 400Hz
VFD 1000V
400V
10Hz ~ 400Hz
600

A
40

A
10Hz ~ 5kHz
6000

A
400

A
10Hz ~ 5kHz
60mA
4mA
10Hz ~ 5kHz
600mA
40mA
10Hz ~ 5kHz
6A
0.6A
10Hz ~ 3kHz
10A
6A
10Hz ~ 3kHz
Accuracy: 0.05%+5d
Hz Logic Level Frequency
RANGE
Accuracy
1) 2)
5.000Hz ~ 1.0000MHz
0.002%+4d
1)
Sensitivity: >3.0Vp square wave
2)
Specified with Pulse Width > 0.5

s
%Duty Cycle
5V Logic Frequency
RANGE Specified
Accuracy
5Hz ~ 1kHz
0.10% ~ 99.99%
3d/kHz+2d
1kHz ~ 10kHz
1.00% ~ 99.00%
10kHz ~ 500kHz
20.00% ~ 80.00%
Sensitivity: >3.0Vp square wave
Non-Contact EF-Detection (NCV)
Bar-Graph Indication
EF-H (Hi Sensitivity)
EF-L (Lo Sensitivity)
Typical Voltage (Tolerance)
-
25V ( 18V ~ 45V)
60V (50V ~ 140V)
- -
50V (30V ~ 80V)
120V (100V ~ 260V)
- - -
80V (70V ~ 160V)
230V (180V ~ 400V)
- - - -
120V (110V ~250V)
400V (330V ~ 490V)
- - - - -
350V (>270V)
600V (>500V)
Indication: Bar-graph segments & audible beep tones proportional to the field strength
Detection Frequency: 50/60Hz
