SystemMaster S2 (Installation Guide) _ FCC_ISED V1.4| 5
B S H H A U S G E R Ä T E G M B H
2.2 Board footprint
The mounting dimensions of the S2 board are those shown below. The described land
pattern and cutout area are parts of the carrier board PCB-layout.
(Unit: mm)
