1.2- Installation
1.2.1 General considerations
It is required to follow step by step this installation guide in order to
achive a correct connection and control over TOUCHEVO and your pool
Along thi section it will be detailed how to install Domopools and how to
identify Domopools operation mode. This will help to install it correctly.
1.2.2 Domopool parts identification
Check the next picture to locate wiring connections: Micro-usb power
cable and Ethernet cable.
Identify push button to change operation mode.
And 4 status LEDs, for operation mode and comunication with
TOUCHEVO
1 Radio Antenna
2 Status LEDs:
Power LED: On the top side. Red LED will light up when micro-usb
power cable is connected. Domopools needs micro-usb power cable
supplied with it.
Operation mode LED: Below Power LED. Green LED is off when local
mode (configuration mode) is activated.
Green LED will light up when Remote mode is activated. It will blink
until Internet signal is settled then it will be lighted up permanently.
3 Push button to change operation mode: Press this button for 10
seconds to change Domopools operation mode Remote -> Local
4 Radio communication LEDs:
Radio Transmitter LED: On the right hand side. Red Transmitter LED
will blink when Domopools is sending information to TOUCHEVO.
Domopools->TOUCHEVO
Radio Receiver LED: On the left hand side, Green Receiver LED will
blink when TOUCHEVO is communicating with Domopools.
Domopools <- TOUCHEVO.
5 Registration serial number: This registration serial number is needed
when user follows Register section. This serial number will be very
important for our technical department if there is any enquiries.
6 Synchronization led
7 Power cable socket: Use micro-usb power cable supplied.
8 Ethernet socket: Ethernet cable (if needed) for Internet connection.
