BTCPower 350 KW EVSE Installation manual Draft
Page 8 of 23
Simplified Block Diagram of Single System:
T
op level system capabilities (350 KW):
Parameter
Specification
Input voltage
480 VAC
3 Phase +/
-
10%, (432
–
528 VAC)
Output voltage range, CCS only
200
-
920 VDC
Output voltage range, CHAdeMO
only
50-500 VDC
Maximum output current, CCS only
(non
–
continuous)
500 Amps
Maximum output current, CCS only
continuous
500Amps. Please see note below
Note:
Rating of the H & S liquid cooled cable
subsystem is to be evaluated for continuous
operation
Rating of all other components except H & S
liquid cooled cable are rated for continuous 500
Amp operation.
200 KW
Power Box
Single Output
Cooling system
350 KW
Dispenser
Single CCS1
CCS 1
Vehicle
DC Outputs Wired in Parallel
200 KW
Power Box
Single Output
