4.DCFCEVDSP-350-5-480-0-1-C-3-0(CHAdeMO+CCS)
DC power Dispenser (Dual Cord):
Auxiliary Input Voltage 120 VAC, single phase, +10%, -10%
Auxiliary Input Current 20 Amps
Frequency 47 – 63 Hz for three phase inputs
Power Quality IEEE-519 and IEC 6200-3-4
Maximum Output Power CCS 350 KW.
Maximum DC Output Current CCS, non-
continuous
500 Amps.
Maximum DC Output Current CCS,
continuous
Note:
Rating of the H & S liquid cooled cable subsystem
is to be evaluated later for continuous operation
Rating of all other components except H & S liquid
cooled cable are for continuous 500 Amp
operation.
Maximum Output Power CHAdeMO 100 KW.
Maximum DC Output Current CHAdeMO,
non-continuous
250 Amps.
Maximum DC Output Current CHAdeMO,
continuous
200 Amps
Minimum Current (In current mode) 5 Amps
DC power input voltage range 50-920 VDC
DC power input current range 5 Amps – 500 Amps
Outdoor enclosure NEMA 4, IP 54 equivalent
Chilled 50/50 ethylene glycol 20 C input Temperature, Flow rate = 10 l/min.
Weight 600 lbs.
5.DCFCEVDSP-350-3-480-0-2-C-3-0(DualCCS)
DC power Dispenser (Single Cord):
Auxiliary Input Voltage 120 VAC, single phase, +10%, -10%
Auxiliary Input Current 20 Amps
Frequency 47 – 63 Hz for three phase inputs
Power Quality IEEE-519 and IEC 6200-3-4
Maximum Output Power CCS 200 KW.
Maximum DC Output Current CCS, non-
continuous
500 Amps.
Maximum DC Output Current CCS,
continuous
Note:
Rating of the H & S liquid cooled cable subsystem is
to be evaluated later for continuous operation
