BTCPower 350 KW EVSE Installation manual Draft
Page 9 of 23
Maximum output current,
CHAdeMO only, (non –
conti
nuous)
250 Amps
Maximum output current,
CHAdeMO only, continuous
200 Amps
System efficiency
Greater than 92%
Power converter efficiency
Greater than 94% at full power
Maximum output power
200
kW
Operating Temperature
-
30 C to + 50 C
Operating
Altitude
9,320 ft.
Relative Humidity
95% non
-
condensing
Dispenser input auxiliary power 120 vac (Single phase), 20 Amps. Both
CHAdeMO + CCS and CCS + CCS models.
Connectors available, CCS only
HPC
-
CCS Huber + Suhner
Connectors available, CHAdeMO
only
SEI Sumitomo Electric 200 Amp Continuous
SEI Sumitomo Electric 250 Amp Non -
Continuous
3.DCFC“PowerBox”specifications:
AC to DC Power Converter Specifications (Per Power Box, 2 Req.)
BTC PN: EVPC-200-2-480-3 (Dual
Output)
BTC PN: EVPC-200-1-480-3 (Single
Output)
Parameter Specification Specification
Input Voltage Range 480 VAC, three phases, +10%, -10% 480 VAC, three phases, +10%, -10%
Input Current @ 480 VAC 240 Amps 240 Amps
Frequency 47 – 63 Hz for three phase inputs 47 – 63 Hz for three phase inputs
Power Quality IEEE-519 and IEC 6200-3-4 IEEE-519 and IEC 6200-3-4
DC Output
Maximum Power 200 KW 200 KW
Max Output Current 500 Amps CCS, 250 Amps CHAdeMO 500 Amps CCS
Minimum Current (In
current mode)
5 Amps 5 Amps
DC Output v
oltage range
50-920 VDC 50-920 VDC
Efficiency > 95% (at full load) power stage only > 95% (at full load) power stage only
Power Factor > 0.99 full load > 0.99 full load
Outdoor enclosure NEMA 4, IP 54 equivalent NEMA 4, IP 54 equivalent
Dimensions (Refer to
DWG 200KW-AFE-T-
00.PDF)
80” High, 41” Width, 33” Deep
Estimated weight, 1,800 lbs.
80” High, 41” Width, 33” Deep
Estimated weight, 1,800 lbs.
