37
Appendix B. - Technical Specifications
General
Frequency Range FRS 462.5500 ~ 467.7250 MHz
Memory Channel 22 FRS Channels + 7 NOAA Weather
Operation Voltage DC3.7V ±10%
Battery Capacity 900mAH (Li-Ion)
Frequency Stability ±2.5ppm
Operating Temperature -20ȭ to +60ȭ
Mode of Operation Simplex
Antenna Impedance 50ohm
Transmitter Part
RF Output Power FRS 2W/0.5W
FM Modulation 11K0F3E@12.5KHz
Adjacent Channel Power 60dB @ 12.5 KHz
Transmission current İ1200mA
Receiver Part
Receive Sensitivity 0.25μV (12dB SINAD)
Adjacent Channel Selectivity ≥55dB@12.5KHz
Inter Modulation and Rejection ≥55dB@12.5KHz
Conducted Spurious Emission ≤-57dB@12.5KHz
Rated Audio Power Output 0.5W @8ohms
Receive current ≤350mA
Rated Audio Distortion ≤5%
NOTE: All specifications may be modified without prior notice or liability. Thank you.
