10
03/10/2016BT00680-c-
346310
230 Vac
2
3
1 32
346210
1
MOD M N/P T
8
BUS
89.24 89.12
90.24 90.12
91.24 91.12
230 Vac
2
3
1 32
346210
1
MOD M N/P T
8
BUS
89.24 89.12
90.24 90.12
91.24 91.12
230 Vac
NC
C
NO
89.24 89.12
90.24 90.12
91.24 91.12
346210
EN
2 WIRE Switchboard
WIRING DIAGRAMS VARIATIONS
Auxiliary services – Additional ringtone (Bell type) remoted via actuator and associated to the SWB
- Repeat the call and alarms sent to the SWB on Bell type ringtone
- In N/P enter the ten and the units of the associated SWB
- The time must not be customised using configurator T
The contact activates and deactivates following the SWB call times.
Call repeater on additional bell type
Badenia
Call repeater on additional bell type
Badenia
Unit
Tens
Auxiliary services – Additional ringtone (Bell type) connected directly to the SWB
The contact activates and deactivates following the SWB call times.
Load of relay contacts: 24 Vac / 24 Vdc
3 A, cosφ = 1
