11
S C S
O UT 1 O UT 2 O UT 3 O U T 4
I N 1 I N 2
I N 3
I N 4
OUT
I N
BUS BUSBUS
03/10/2016BT00680-c-
346310
391670
347400
P
= –
= –
N = –
Z = –
M = –
A = –
PL = –
P
= –
= –
N = –
Z = –
M = –
A = –
PL = –
P
= –
= –
N = –
Z = –
M = –
A = –
PL = –
EN
2 WIRE Switchboard
Camera to be used with the SWB
In the SWB menu declare the presence of the associated camera.
In the camera P enter the SWB address to which it is associated.
Tlc 12 Vdc
150 mA
max 3 m
To the internal units
To the SWB
Main Entrance Panel
(P = 1)
To the camera
Possible options
Coaxial/2 WIRE
interface
2 WIRE flush
mounted
camera
