Configurators and
wiring accessories
3501/1 3501/2 3501/3
3501/4 3501/5
3501/6
3501/7 3501/8 3501/9
3501/GEN 3501/AMB
3501/SLA
Item Description
3501/0 configurator 0
3501/1 configurator 1
3501/2 configurator 2
3501/3 configurator 3
3501/4 configurator 4
3501/5 configurator 5
3501/6 configurator 6
3501/7 configurator 7
3501/8 configurator 8
3501/9 configurator 9
3501/GEN configurator GEN
3501/AMB configurator AMB
3501/SLA configurator SLA
CONFIGURATORS ONE-TYPE PACKAGE OF 10 PIECES
CONFIGURATOR KIT
➝
➝
➝
➝
3501K/1
346000 336904
Item Description
346000 power supply for sound system – input 230Va.c. output 27Vd.c.
– maximum current supplied 1200 mA – fastening on DIN rail with
size 8 modules
POWER SUPPLY
Item Description
336904 twisted 2-conductor cable which can be buried in piping – corre-
sponds to standards IEC 20-13 and IEC 20-14 – coil length 200 m
CABLE FOR SYSTEMS
Item Description
3499 line terminator – to be installed on the used outputs of the audio/
video node
LINE TERMINATOR
VARIOUS ACCESSORIES
26
MY HOME - 2 WIRE SOUND SYSTEM GENERAL RULES FOR INSTALLATION
Item Description
3501K Configurator kit from 0 to 9
3501K/1 Configurator kit AUX, GEN, GR, AMB,ON, OFF, O/I, PUL, SLA, CEN,
, M
3501K
3499
3515
335919
3559
Item Description
3515 spare pull-out terminal
335919 cable to connect the TOUCH SCREEN to the PC to program the device
3559 cable above - for USB port
