TECHNICAL FEATURES
Loudspeakers
FLUSH-MOUNTED ITEM L/N/NT4565
Type: broadband
Power: 6Wrms/12W musical
Impedance: 16o
Frequency range: 160 to 16kHz
Sensitivity: 80dB (1W/1m)
Feature: loudspeaker to be installed in flush-mounted boxes item 506E
Technical data
WALL-MOUNTED ITEM L4567
Type: 2 way
Power: 20Wrms/40W musical
Impedance: 8o
Frequency range: 75 to 20kHz
Sensitivity: 88dB (1W/1m)
Weight: 1 Kg
Feature: shallow loudspeaker to be installed on the wall (complete with
fastening screw and 4 m of cable)
Dimensions: 271 x 184 x 37 mm
Technical data
FOR INSTALLATION ON THE CEILING ITEM L4566
Type: 2 way coaxial
Power: 50Wrms/100W musical
Impedance: 8o
Frequency range: 50 to 20kHz
Sensitivity: 88dB (1W/1m)
Weight: 1.7Kg
Feature: loudspeaker to be installed on the ceiling
Diameter mounting hole: 210 mm
External diameter: 240 mm
Depth: 140 mm
Technical data
