Bticino PIVOT - Example MOD 7 (Two-Family Systems)

7
BT00653-a
346812
-EN
TECHNICAL SHEETS
Conguration
Example 8 - MOD = 7 Intercom in two-family systems
- Key
1
Calls the handsets of the same apartment (the handsets congured with the same N as the one the call is made from)
- Key
2
Calls the handsets of the other apartment (the handsets congured with a dierent N from the one the call is made from)
- Key
3
Opens the door lock associated with the EP congured with P + 1
- Key
4
Opens the door lock associated with the EP congured with P + 2
3
PS
BU S
TK
BU S
PI
230 Vac
1
2
3
4
1
2
3
4
2
2
22
346830
NP
2
NP
2
NP
1
BUS 2 1
346000
BUS
MOD=7
P=0 P=1
PE
main
PE
main (P+1)
Power supply
BUS
MOD=7
NP
1
2
NP
1
Apartment 2
NP
2
Apartment 1
2 2 2
PE
audio (P+2)
P=2
4
O
O
O
O
P=2P=1P=0
NOTE: Maximum 3 devices per apartment.
Press repeatedly
for entrance panel cycling.
It calls the handsets (general call)
congured with 2 (other devices
in apartment 2), same apartment
intercom
It calls the handsets (general
call) congured with 1 (devices in
apartment 1), intercom between
apartments
It calls the handsets (general call)
congured with 1 (other devices
in apartment 1), same apartment
intercom
It calls the handsets (general
call) congured with 2 (devices in
apartment 2), intercom between
apartments
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
NOTE: Maximum 3 PIVOT devices per apartment
with MASTER-SLAVE function.
