BÜCHI Vac V-511/512/5135 Operation
Fig. 11: Front of Vac V-513
5 Operation
Please be sure that the apparatus has been properly installed
according to the instructions in Chapter 4, Beginning Opera-
tion.
5.1 Vacuum Systems
햲 Main switch vacuum system
햳 Vacuum Controller V-800 (only for V-512 and V-513)
햴 Additional condenser (only for V-511 and V-513)
햵 Valve unit (only for V-512 and V-513)
햶 Main switch V-800
Fig. 12: Vac V-513 from the side
햵
햶
햴
햲
햳
