BÜCHI Vac V-511/512/5138 Spare parts and Accessories
8 Spare parts and Accessories
Only original spare parts and accessories from BÜCHI guaran-
tee that the apparatus will function properly and safely. Spare
parts and accessories from other manufacturers may be used
only with the express permission of BÜCHI AG. General safety
regulations and Chapter 6 must be observed when assembling
or dismantling the apparatus. Before putting the apparatus in-
to operation, please check that it is fully functional as described
in Chapter 6.1. Production according to this manual is forbidden.
The copyright is owned by the firm Büchi Labortechnik AG.
8.1 Spare parts
1 Spare parts set with 2 valve heads 38120
and 2 diaphragms
1 Glass head set (with 1 glass head) 37966
1 Valve head set (with 2 valve heads) 38025
1 Diaphragm set (with 1 diaphragm) 38020
1 GL-14 screw set 37999
(with PTFE hose, 4GL-14)
1 Set hose connections (4 x bent / 38000
2 x straight / 6 x screw caps)
1 Control cable Vacuum Controller 38010
V-800 to V-500, or B-721 to 721
1 Secondary condenser 37775
1 Holder for secondary condenser 38086
and collecting tank
1 Collecting tank for secondary condenser 37949
1 Spring lock washer 37872
1 Gasket for secondary condenser or 37873
valve unit
1 Collecting beaker for valve unit 38005
1 Signal cable for KNF vacuum controller 38015
1 Signal cable for Vacuubrand 38014
vacuum controller
1 Sound absorber 37947
1 Rubber vacuum hose, 2 m 17622
1 PVC vacuum hose, 2 m 04113
1 Cooling water hose, 2 m 04133
1 Stand with holder for valve unit/ 38021
secondary condenser
1 Valve unit complete 37968
1 Cable set for combination with 31466
Rotavapor R-134/144 or B-168
1 Cooling water valve 31356
1 Thermostatic jacket for 37616
secondary condenser
1 Installation tool 38614
1 Set of valve reeds 41977
Table 6: Spare parts
Fig. 16: Spare parts 1
37966
38000
38025
38020
37999
38614
