BÜCHI Vac V-511/512/513 3 Function
Büchi Vac V-512
햴 Main switch
햵 Vacuum Controller V-800
Büchi Vac V-513
햲 Additional condenser
햳 Collecting tank
햴 Main switch
햵 Vacuum Controller V-800
Fig. 6: Vac V-513
Fig. 5: Vac V-512
