4.0 Operation
4.1 Charger
1. Connect a suitable main plug to the charger, the plug should be fitted with a fuse
of 1Amp or 3 Amp rating. Connect the Brown wire to the Live (L) terminal and
the Blue wire to the Neutral (N) terminal There is no connection to the Earth (E)
terminal.
2. The BCM as supplied may not be fully charged, it is recommended that the BCM
is charged for 24hours before initial use.
3. Connect the charger to the BCM. Check the orientation of the plug on the charger
as it will only connect one way.
4. Connect the charger to the mains supply, the Green led light in the centre of the
charger should illuminate, if not check the connection to the BCM and that the
mains power is on.
5. The normal time to re-charge the battery from flat is 14 hours, but it can be left on
charge for up to 48 hours without damage to the battery. The battery can be
topped up after use by giving a charge of 12 minutes for each hours use.
6. There is no indication on the charger or the BCM that the battery is charged. If the
charger is turned off it will not discharge the BCM.
7. When charging is complete, disconnect the charger from the mains supply and
then from the BCM.
4.2 BCM Unit
1. Fit a pointed probe tip to the end of the instrument using a smear of Silicone
grease to help stop damage to the “O” ring seal. Use the spanner provided to make
sure that the probe tip is fully home.
2. Smear the Blanking Plug Pins with some Silicone grease and insert the plug into
the socket in the handle of the BCM. This switches the BCM on.
3. Screw the White Blanking Plug retaining ring into the handle to stop the Blanking
Plug from being accidentally removed. NOTE:- The Blanking Plug must NOT be
removed under water.
4. The unit as supplied has been fully tested and calibrated in the factory. However
some drying out of the reference electrode may have occurred and it is
recommended that prior to initial use the unit is soaked in Seawater for 20 to 30
minutes.
5. The BCM is now ready for use. If required the calibration can be checked, see
section on Calibration.
