BuckMaster 261 - Page 25

Page 23
Figure 18.
MASONRY CHIMNEY
CLEAN OUT
DOOR
MASONRY
FLUE
LINERS
8"
Figure 17.
A. Rear exit into Masonry Flue using (6" Single Wall pipe
minimum 24 ga blued or black pipe).
With standard close clearance shield and pipe shield.
Model 261 minimum clearance to combustibles.
BACK WALL
SIDE WALL
A
E
B
F
C
C
D
G
C
C
BACK WALL
SIDE WALL
A
E
B
F
C
C
D
G
A
E
B
F
BACK WALL
SIDE WALL
PROTECTOR
D
A B C D E F G
MODEL 261 13” 13" 13" 20" 8" 3" 10"
NEW BUCK
CAST COLLAR
Part# MA6CHIMCNB
CEILING
NOTE: All clearances are to combustibles with all low clearance shields and single wall pipe ,
and minimum floor protector. NOTE: Floor protector must extend length of
horizontal flue pipe to wall. NOTE: Model 261 comes standard with low clearance shields.
G
( NOTE: )
MINIMUM CLEARANCES FROM
TOP OF UNIT TO MANTEL OR
MANTEL SUPPORTS
“ 14 1/2" MINIMUM “
8"
