BuckMaster 261 - Alcove Installation

Page 37
NOTE: All clearances are to combustibles with all low clearance shields and double wall pipe ,
and minimum floor protector. NOTE: Floor protector must extend length of
horizontal flue pipe to wall. NOTE: Model 261 comes standard with low clearance shields.
A B D E F G H I
MODEL 261 14" 4" 20" 8" 3” 47" 10" 84"
LISTED 2100° UL 103 HT TYPE CHIMNEY
REEFER TO MANUFACTURERS
INSTALLATION INSTRUCTION
LISTED 2100° UL 103 HT TYPE
CHIMNEY T-BOX ASSEMBLY
REEFER TO MANUFACTURERS
INSTALLATION INSTRUCTION
IN
SIDE
WALL
Figure 32.
CEILING
Figure 31
BACK WALL
SIDE WALL
A
E
B
F
C
C
D
G
D D
BACK WALL
SIDE WALL
A
C
D
B
E
G
A
E
SIDE WALL
BACK WALL
I
C
BUCK STOVE
E
H
B
ALCOVE INSTALLATION
AND CLEARANCES
B-1. Alcove Rear exit using (6" DVL Close Clearance pipe, and any
listed 2100° UL 103 HT TYPE Chimney).
With standard close clearance shield and pipe shield.
Model 261 minimum clearance to combustibles.
PROTECTOR
F
D
