Page 45
SECTION VI
OPTIONAL MOTOR ASSEMBLY KIT INSTALLATION
INSTRUCTIONS
STEP 1. REMOVE ACCESS DOOR PANEL LOCATED AT BOTTOM OF
UNIT. YOUR MOTOR ASSEMBLY COMES WITH A BRACKET
ALREADY ATTACHED TO MOTOR. ALIGN HOLES IN MOTOR
BRACKET WITH HOLES IN MOTOR MOUNT. SECURE
BRACKET WITH TWO 1/2” HEX HEAD SCREWS PROVIDED.
STEP 2. REMOVE PROTECTIVE BACKING OFF RHEOSTAT INDICATING
LABEL AND PLACE HOLE IN CENTER OF LABEL TO LINE UP
WITH HOLE IN RIGHT SIDE HEARTH SUPPORT AS YOU FACE
UNIT. PLACE LABEL SO “OFF” POSITION IS AT THE 8 O’CLOCK
POSITION AND LOW IS AT THE 4 O’CLOCK POSITION. MOUNT
RHEOSTAT BY PLACING IT BEHIND HEARTH SUPPORT WITH
WIRES ON BOTTOM SIDE. PLACE PLASTIC STUD THROUGH
HOLE IN BRACKET AND SECURE WITH RHEOSTAT
MOUNTING NUT. PLACE INDICATOR KNOB ON PLASTIC
STUD.
STEP 3. REMOVE STRAIN RELIEF COVER FROM HEARTH SUPPORT
AND DISCARD. MOUNT POWER CORD STRAIN RELIEF
HOLDER IN COVER MOUNTING HOLES. PLACE THERMOSTAT
BEHIND “C” CLIP LOCATED UNDER HEARTH TO RIGHT OF
MOTOR. USE CABLE TIE TO SECURE LOOSE WIRES.
STEP 4. REINSTALL ACCESS DOOR PANEL.
STEP 5. PLUG POWER CORD INTO SUPPLY OUTLET. PLACE
RHEOSTAT INDICATING KNOB IN DESIRED POSITION. WHEN
HEATER REACHES TEMPERATURE, FAN WILL OPERATE AT
DESIRED SPEED.
