Buell S1 Lightning 1996 User Manual

1-6
Figure 1-1. 1996 S1 Lightning, Right Side View
Figure 1-2. 1996 S1 Lightning, Right Side View (Body Removed)
1. Right rear turn signal
2. Tail/brake lamp
3. Rear brake master cylinder
and reservoir
4. Air cleaner cover
5. Fuel filler cap
6. Front brake master cylinder
7. Front brake hand lever
8. Right front turn signal
9. Headlamp
10. Front brake caliper
11. Timer cover
12. Rear shock absorber
13. Rear brake pedal
14. Belt guard(s)
15. License plate light
5745
5
6
4
7
11121314
9
10
1
8
32
15
1. Rear axle adjuster nut
2. Rear sprocket and secondary
drive belt
3. Ignition module
4. Fuse block and spare fuse
5. Turn signal flasher
6. Horn
7. Front brake master cylinder
8. Front brake hand lever
9. Front brake caliper
10. Oil pump
11. Battery
12. Voltage regulator
13. Rider footrest
14. Passenger footrest
5746
3
7
1
2
8
9
4 5 6
1011121314
SIDE VIEWS
