WARNINGS
• Only apply the parking brake when the buggy is stationary.
frame
The frame is fastened to the chassis; the chassis is then secured. The carrycot or seat fabric is
attached to the frame. The frame has 2 frame supports, which ‘click’ onto the 2 frame bearers.
The round side of the frame is always the head end of the carrycot or seat.
step 6 fitting the frame on the chassis
Place the frame bearers in the upright position. Now fit the frame.
a Squeeze together the squeeze-fastener on the centre
shaft. This releases the frame bearers.
b. Place the frame bearers in the upright position.
c Let go of the squeeze-fastener. You will hear a ‘click’.
The frame bearers are now locked.
