Nivotemp NT 61D, Nivovent NV 71D
Alternative temperature outputs -2T -1T-KT -4T
Plug (base) 2 x M12 – 4-pin 2 x M12 – 4-pin 1 x M12 – 4-pin 1 x M12 – 8-pin
Switching outputs
2 x freely programmable* 1 x freely programmable* 4 x freely programmable
Alarm memory with 1 x assignable to alarm
logbook
with 1 x assignable to alarm
logbook
max. switching current** 0.5 A per output
continuous short-circuit
protected
0.5 A per output
continuous short-circuit
protected
0.5 A per output
continuous short-circuit
protected
Contact load max. 1 A total max. 1 A total max. 1 A total
Analogue output 1 x 4 – 20 mA 2-10 V DC,
0-10 V DC, 0-5 V DC
Max. burden Ω as current output = (U
B
-8 V) / 0.02 A
Min. input load as voltage output 10 kΩ
Options
: Stilling tube SSR (same material as immersion tube)
*also programmable as frequency output
**Output 1 max. 0.2 A.
